TC 40 0,16 32

Name: TC 40 0,16 32 - KOCO MOTION
SKU: TC 40 0,16 32

Loggen Sie sich ein, um Preise für dieses Produkt zu sehen

inkl. 19 % MwSt.

Flange dimensions: 40 mm
Rated Output Power: 60 – 100 W
Rated Torque: 0,19 – 0,32 Nm
Rated Speed: 3000 rpm

Artikelnummer: TC 40 0,16 32 Kategorie: Servo Motors

Beschreibung

Beschreibung

Flange dimensions: 40 mm
Rated Output Power: 60 – 100 W
Rated Torque: 0,19 – 0,32 Nm
Rated Speed: 3000 rpm

Specification	TC 40 0,16 32
Continous Stall Torque	0.21 Nm
Peak Torque	0.48 Nm
Nominal Torque	0.19 Nm
Rated Voltage	24 V
Nominal power	60 W
Continuous stall Current	4.23 Arms
Maximun Current	9.67 Arms
Nominal Current	3.96 Arms
Nominal working Speed	3000 rpm
Maximum working speed 24VDC	5000 rpm
Maximum working speed 48VDC	–
Maximum working speed 230VAC	–
Torque Constant	0.05 Nm/Arms
Voltage Constant	3 Vrms/Krpm
Winding resistance	1 Ω
Winding inductance	0.7 mH
Electrical time constant	0.7 ms
Thermal Resistance	2.38 °C/W
Mechanical time constant	1.62 ms
Rotor Inertia without brake and without feedback	0.027 kg·cm²
Mass without holding brake	0.4 Kg
Mass with holding brake	0.54 Kg
Mass without holding brake with absolute encoder	0.41 Kg
Mass with holding brake with absolute encoder	0.61 Kg
Maximum axial shaft load applied on the shaft’s center	30 N
Maximun radial shaft load applied on the shaft’s center	180 N

Family Specification	TC 40 0,16 32
Time Rating	Continuous
Insulation Class	F
Enclosure	Totally enclosed. Self-cooled
Protection Class	IP 65 standard on the body
Insulation System UL/CSA	cURus , DV155J File nr. : E216686
Ambient Temperature	0 to 40 °C
Ambient Humidity	5 to 85% (non-condensing) %
Poles	8
Thermal Protection	Not available
Certification	CE
Recommendation	Rated output with 250 x 250 x 6 mm metallic heat sink flange coupling – Derating must be considered if the oil seal is applied – IP 54 standard shaft bushing

Family Overview	TC 40 0,16 32
Flange dimensions	40 mm
Rated Output Power	60 – 100 Watt
Rated Torque	0,19 – 0,32 Nm
Rated Speed	3000 rpm

Optionen

Mechanical Arrangement

0 = Shaft with key / without oil seal (front flange side IP 54) 1 = Shaft with key / with oil seal (front flange side IP 65) 2 = Shaft without key / without oil seal (front flange side IP 54) 3 = Shaft without key / with oil seal (front flange side IP 65)

Feedback

E1 = Encoder TTL 2000 ppr R1 = Resolver 2p A1 = Absolute multiturn encoder

Brake

0 = without brake 1 = with brake

Connection

D0 = 300mm cable length with AMP connectors, without thermal protection, specify D0/F88 if the connection is with Lite Pro drive G2 = 90° M23 turnable connectors – PT 1000 on power connector specify G2/F88 if the connection is with Lite Pro drive H2 = 90° M23 turnable connectors – PT 1000 on signal connector specify H2/F88 if the connection is with Lite Pro drive

Anwendungen

Medical Biomedical Agriculture Processing & Packaging Logistic & Intralogistic

Technische Angaben dienen als Orientierungswerte, da die einzelnen Antriebe und Motoren anwendungsbezogen konfiguriert werden. Technische und optische Änderungen vorbehalten.

TC 40

Datenblatt

Dimensions-TC (pdf, 375.15K)

Torque-Speed-Chart (pdf, 559.55K)

TC-Servo-Drive (pdf, 3.02M)

TC-Feedback-Features (pdf, 162.32K)

TC-Thermal-Protection-Features (pdf, 256.31K)

TC-Brake-Features (pdf, 256.12K)

TC-Wiring-Cables-Connectors (pdf, 1.86M)
