Coreless Motors

Coreless Motors belong to the energy-efficient brushed drives due to their self-supporting winding. This is why they are often used in battery application.

215 Produkte entsprechen den Kriterien

Sortierung:

|

Ansicht:

0615N5M01-122-3.0

Max. output power 0.11W

Max. efficiency 56%

Back-EMF constant 0.2mV/rpm

Torque constant 2.2mNm/A

0615N5M02-185-3.0

Max. output power 0.09W

Max. efficiency 44%

Back-EMF constant 0.1mV/rpm

Torque constant 1.4mNm/A

0615N5M03-295-6.0

Max. output power 0.83W

Max. efficiency 67%

Back-EMF constant 0.2mV/rpm

Torque constant 1.9mNm/A

0816N5M02-137-4.2

Max. output power 0.3W

Max. efficiency 61%

Back-EMF constant 0.3mV/rpm

Torque constant 2.8mNm/A

0816N5M11-148-6.0

Max. output power 0.34W

Max. efficiency 69%

Back-EMF constant 0.4mV/rpm

Torque constant 3.8mNm/A

0816N5M01-155-8.0

Max. output power 0.24W

Max. efficiency 62%

Back-EMF constant 0.5mV/rpm

Torque constant 4.7mNm/A

1020N5M52-115-3.0

Max. output power 0.57W

Max. efficiency 74%

Back-EMF constant 0.3mV/rpm

Torque constant 2.4mNm/A

1020N5M14-125-6.0

Max. output power 0.72W

Max. efficiency 69%

Back-EMF constant 0.5mV/rpm

Torque constant 4.4mNm/A

1020N5M16-280-7.4

Max. output power 4.04W

Max. efficiency 78%

Back-EMF constant 0.3mV/rpm

Torque constant 2.5mNm/A

1024N5M02-130-6.0

Max. output power 1.32W

Max. efficiency 73%

Back-EMF constant 0.5mV/rpm

Torque constant 4.3mNm/A
