TC 100 3,2 21

Name: TC 100 3,2 21 - KOCO MOTION
SKU: TC 100 3,2 21

Loggen Sie sich ein, um Preise für dieses Produkt zu sehen

inkl. 19 % MwSt.

Flange dimensions: 100 mm
Rated Output Power: 820 – 1570 W
Rated Torque: 2,61 – 5,0 Nm
Rated Speed: 3000 rpm

Artikelnummer: TC 100 3,2 21 Kategorie: Servo Motors

Beschreibung

Beschreibung

Flange dimensions: 100 mm
Rated Output Power: 820 – 1570 W
Rated Torque: 2,61 – 5,0 Nm
Rated Speed: 3000 rpm

Specification	TC 100 3,2 21
Continous Stall Torque	3.2 Nm
Peak Torque	11 Nm
Nominal Torque	2.61 Nm
Rated Voltage	230 V
Nominal power	820 W
Continuous stall Current	6.08 Arms
Maximun Current	20.91 Arms
Nominal Current	5.11 Arms
Nominal working Speed	3000 rpm
Maximum working speed 230VAC	5000 rpm
Maximum working speed 400VAC	–
Torque Constant	0.526 Nm/Arms
Voltage Constant	31.8 Vrms/Krpm
Winding resistance	1.1 Ω
Winding inductance	4.44 mH
Electrical time constant	4.03 ms
Thermal Resistance	1 °C/W
Mechanical time constant	0.92 ms
Rotor Inertia without brake and without feedback	1.55 kg·cm²
Mass without holding brake	3.9 Kg
Mass with holding brake	5.2 Kg
Maximum axial shaft load applied on the shaft’s center	225 N
Maximun radial shaft load applied on the shaft’s center	626 N

Family Specification	TC 100 3,2 21
Time Rating	Continuous
Insulation Class	F
Enclosure	Totally enclosed. Self-cooled
Protection Class	IP 65 standard on the body
Insulation System UL/CSA	cURus , DV155J File nr. : E216686
Ambient Temperature	0 to 40 °C
Ambient Humidity	5 to 85% (non-condensing) %
Poles	8
Thermal Protection	PT 1000
Certification	CE
Recommendation	Rated Output with 300 x 300 x 6 mm aluminum heat sink flange coupling – Derating must be considered if the oil seal is applied – IP 54 standard shaft bushing

Family Overview	TC 100 3,2 21
Flange dimensions	100 mm
Rated Output Power	820 – 1570 Watt
Rated Torque	2,61 – 5,0 Nm
Rated Speed	3000 rpm

Optionen

Mechanical Arrangement

0 = Shaft with key / without oil seal (front flange side IP 54) 1 = Shaft with key / with oil seal (front flange side IP 65) 2 = Shaft without key / without oil seal (front flange side IP 54) 3 = Shaft without key / with oil seal (front flange side IP 65)

Feedback

E1 = Encoder TTL 2000ppr R1 = Resolver 2p A1 = Absolute multiturn encoder

Brake

0 = without brake 1 = with brake

Connection

D0 = 300mm cable lenght with AMP connectors, without thermal protection (For TC40 only) specify D0/F88 if the connection is with Lite Pro drive G2 = 90° M23 turnable connectors – PT 1000 on power connector specify G2/F88 if the connection is with Lite Pro drive H2 = 90° M23 turnable connectors – PT 1000 on signal connector specify H2/F88 if the connection is with Lite Pro drive

Anwendungen

Medical Biomedical Agriculture Processing & Packaging Logistic & Intralogistic

TC 100

Datenblatt

Dimensions (pdf, 654.19K)

Torque-Speed-Chart (pdf, 447.9K)

TC-Servo-Drive (pdf, 3.02M)

TC-Feedback-Features (pdf, 162.32K)

TC-Thermal-Protection-Features (pdf, 256.31K)

TC-Brake-Features (pdf, 256.12K)

TC-Wiring-Cables-Connectors (pdf, 1.86M)
