C12**—12MS—C1215F13-0462

Name: C12**-12MS-C1215F13-0462 - KOCO MOTION
SKU: C12**---12MS---C1215F13-0462

Loggen Sie sich ein, um Preise für dieses Produkt zu sehen

inkl. 19 % MwSt.

12mm 1.5V micro DC spur gearmotor

Artikelnummer: C12**—12MS—C1215F13-0462 Kategorie: Spur Gear

Beschreibung

Beschreibung

12mm 1.5V micro DC spur gearmotor

Specification	C12**—12MS—C1215F13-0462
Voltage	1.5 A
Terminal resistance	1.2 Ω
No-load speed	11800 rpm
No-load current	100 mA
Stall torque	1.28 mNm
Stall current	1250 mA
Nominal torque	0.60 mNm
Nominal speed	6287 rpm
Nominal current	640 mA
Max. output power	0.40 W
Max. efficiency	51 %
Back-EMF constant	0.12 mV/rpm
Torque constant	1.12 mNm/A
Speed/torque gradient	9188 rpm/mNm
Rotor inertia	0.3 g·cm²
Weight	5.4 g

Gearbox characteristics

C12**—12MS—C1215F13-0462

Gearbox stages

Reduction ratio

3.5.10

Max. rated torque

mNm

Max. momentary torque

mNm

Length（L）

Gearbox stages

Reduction ratio

17.20.30.36

Max. rated torque

mNm

Max. momentary torque

mNm

Length（L）

Gearbox stages

Reduction ratio

50.63.100

Max. rated torque

mNm

Max. momentary torque

120

mNm

Length（L）

Gearbox stages

Reduction ratio

110.150

Max. rated torque

mNm

Max. momentary torque

150

mNm

Length（L）

Gearbox stages

Reduction ratio

210.250.298.380

Max. rated torque

mNm

Max. momentary torque

240

mNm

Length（L）

Gearbox stages

Reduction ratio

372.625.1000

Max. rated torque

100

mNm

Max. momentary torque

300

mNm

Length（L）

Optionen

lead wires length special coils

Anwendungen

medical equipment scientific instruments industrial equipment
