| Motor Characteristics | C20**—20*P—C2032F41-0141 |
|---|---|
| Voltage | 6.0 V |
| Terminal resistance | 3.8 Ω |
| No-load speed | 7600 rpm |
| No-load current | 100 mA |
| Stall torque | 10.5 mNm |
| Stall current | 1562 mA |
| Nominal torque | 1.80 mNm |
| Nominal speed | 6300 rpm |
| Nominal current | 350 mA |
| Max. output power | 2.10 W |
| Max. efficiency | 57 % |
| Back-EMF constant | 0.74 mV/rpm |
| Torque constant | 7.06 mNm/A |
| Speed/torque gradient | 724 rpm/mNm |
| Rotor inertia | – |
| Weight | 33 g |
| Gearbox characteristics | C20**—20*P— | ||
|---|---|---|---|
| Gearbox stages | 2 | ||
| Reduction ratio | 16~36 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
||
| Gearbox stages | 3 | ||
| Reduction ratio | 64~216 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
||
| Gearbox stages | 4 | ||
| Reduction ratio | 256~1296 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
Applications
medical equipment
scientific instruments
industrial equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
C20**—20*P—
| Specification | C20**—20*P—C2032F41-0141 |
|---|---|
| Voltage | 6.0 V |
| Terminal resistance | 3.8 Ω |
| No-load speed | 7600 rpm |
| No-load current | 100 mA |
| Stall torque | 10.5 mNm |
| Stall current | 1562 mA |
| Nominal torque | 1.80 mNm |
| Nominal speed | 6300 rpm |
| Nominal current | 350 mA |
| Max. output power | 2.10 W |
| Max. efficiency | 57 % |
| Back-EMF constant | 0.74 mV/rpm |
| Torque constant | 7.06 mNm/A |
| Speed/torque gradient | 724 rpm/mNm |
| Rotor inertia | – g·cm² |
| Weight | 33 g |
Applications
medical equipment
scientific instruments
industrial equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
