Inner Rotor

The Brushless DC Motors uses electronic commutation instead of mechanical commutation. As a result, it works very reliably and achieves a long service life.

109 products matching criteria

Sort:

|

View:

B0815N2B02-81-3.7

Terminal resistance 36.5Ω

No-load speed 8100rpm

No-load current 0.02A

Stall torque 0.32mNm

B0815N2B04-200-5.0

Terminal resistance 12Ω

No-load speed 20000rpm

No-load current 0.06A

Stall torque 0.73mNm

B0815N2B05-323-3.7

Terminal resistance 3.1Ω

No-load speed 32300rpm

No-load current 0.1A

Stall torque 1.1mNm

B1020N01-393-7.4

Terminal resistance 1.08Ω

No-load speed 39300rpm

No-load current 0.32A

Stall torque 11.2mNm

B1020N03-85-3.7

Terminal resistance 6.2Ω

No-load speed 8500rpm

No-load current 0.07A

Stall torque 1.9mNm

B1020N05-382-7.4

Terminal resistance 1.4Ω

No-load speed 38200rpm

No-load current 0.24A

Stall torque 8.9mNm

B1023NH2B05-382-7.4

Terminal resistance 1.4Ω

No-load speed 38200rpm

No-load current 0.24A

Stall torque 8.8mNm

B1023NH2B08-146-6.0

Terminal resistance 6.5Ω

No-load speed 14600rpm

No-load current 0.04A

Stall torque 3.30mNm

B1023NH2B09-315-15.0

Terminal resistance 9Ω

No-load speed 31500rpm

No-load current 0.08A

Stall torque 6.8mNm

B1215N2B09-350-3.6

Terminal resistance 0.67Ω

No-load speed 35000rpm

No-load current 0.3A

Stall torque 4.7mNm
