T 180 47 17

Name: T 180 47 17 - KOCO MOTION
SKU: T 180 47 17

Loggen Sie sich ein, um Preise für dieses Produkt zu sehen

inkl. 19 % MwSt.

Flange dimensions: 180 mm
Rated Output Power: 4700 – 8380 W
Rated Torque: 18,0 – 40,0 Nm
Rated Speed: 3000 rpm

Artikelnummer: T 180 47 17 Kategorie: Servo Motors

Beschreibung

Beschreibung

Flange dimensions: 180 mm
Rated Output Power: 4700 – 8380 W
Rated Torque: 18,0 – 40,0 Nm
Rated Speed: 3000 rpm

Specification	T 180 47 17
Continous Stall Torque	50 Nm
Peak Torque	130 Nm
Nominal Torque	40 Nm
Rated Voltage	400 V
Nominal power	8380 W
Continuous stall Current	31.2 Arms
Maximun Current	81 Arms
Nominal Current	26.2 Arms
Nominal working Speed	2000 rpm
Maximum working speed 230VAC	2200 rpm
Maximum working speed 400VAC	3000
Torque Constant	1.6 Nm/Arms
Voltage Constant	97 Vrms/Krpm
Winding resistance	0.19 Ω
Winding inductance	1.4 mH
Electrical time constant	7.4 ms
Thermal Resistance	0.25 °C/W
Mechanical timeconstant high rotor inertia	2.1 ms
Mechanical time constant low rotor inertia	1.5 ms
High rotor inertia (as an option) without brake and without feedback	186.7 kg·cm²
Low rotor inertia (as an option) without brake and without feedback	135.5 kg·cm²
Mass without holding brake	45 Kg
Mass with holding brake	51 Kg
Maximum axial shaft load applied on the shaft’s center	510 N
Maximun radial shaft load applied on the shaft’s center	1700 N

Family Specification	T 180 47 17
Time Rating	Continuous
Insulation Class	F
Enclosure	Totally enclosed. Self-cooled
Protection Class	IP 65 standard on the body
Insulation System UL/CSA	cURus , DV155J File nr. : E216686
Ambient Temperature	0 to 40 °C
Ambient Humidity	5 to 85% (non-condensing) %
Poles	6
Thermal Protection	PT 1000
Certification	CE
Recommendation	Rated output with 500 x 500 x 30 mm metallic heat sink flange coupling – Derating must be considered if the oil seal is applied – IP 54 standard shaft bushing

Family Overview	T 180 47 17
Flange dimensions	180 mm
Rated Output Power	4700 – 8380 Watt
Rated Torque	18,0 – 40,0 Nm
Rated Speed	3000 rpm

Optionen

Feedback

E1 = Encoder TTL 2000ppr R1 = Resolver 2p A1 = Absolute multiturn encoder

Brake

0 = without brake 1 = with brake

Connection

D0 = 300mm cable lenght with AMP connectors, without thermal protection (For TC40 only) specify D0/F88 if the connection is with Lite Pro drive G2 = 90° M23 turnable connectors – PT 1000 on power connector specify G2/F88 if the connection is with Lite Pro drive H2 = 90° M23 turnable connectors – PT 1000 on signal connector specify H2/F88 if the connection is with Lite Pro drive

Anwendungen

Medical Biomedical Agriculture Processing & Packaging Logistic & Intralogistic

Technische Angaben dienen als Orientierungswerte, da die einzelnen Antriebe und Motoren anwendungsbezogen konfiguriert werden. Technische und optische Änderungen vorbehalten.

TC 180

Datenblatt

Dimensions (pdf, 462.4K)

Torque-Speed-Chart (pdf, 407.47K)

TC-Servo-Drive (pdf, 3.02M)

TC-Feedback-Features (pdf, 162.32K)

TC-Thermal-Protection-Features (pdf, 256.31K)

TC-Brake-Features (pdf, 256.12K)

TC-Wiring-Cables-Connectors (pdf, 1.86M)
