Loggen Sie sich ein, um Preise für dieses Produkt zu sehen
inkl. MwSt.
Size 14 [35mm] Stepper Lead Screw Linear Actuator is widely used for linear movement applications, providing up to 230N of continuous thrust.
Size 14 Stepper Lead Screw Linear Actuator has four form factors available – External, Non-Captive, Electrical Cylinder (Captive) and Kaptive.
Size 14 [35mm] Stepper Lead Screw Linear Actuator is widely used for linear movement applications, providing up to 230N of continuous thrust.
Size 14 Stepper Lead Screw Linear Actuator has four form factors available – External, Non-Captive, Electrical Cylinder (Captive) and Kaptive.
![SLSLA - Size 14 [35mm]](https://www.kocomotion.de/wp-content/uploads/2024/06/stepper_size1435mm-300x300.png)
inkl. 19 % MwSt.
Weiterlesen![SLSLA - Size 11 [28mm]](https://www.kocomotion.de/wp-content/uploads/2024/06/stepper_size1128mm-300x300.png)
inkl. 19 % MwSt.
Weiterlesen![SBSLA - Size 8 [20mm]](https://www.kocomotion.de/wp-content/uploads/2024/06/Ball_size820mm-300x300.png)
inkl. MwSt.
Produkte anzeigen![SLSLA - Size 8 [20mm]](https://www.kocomotion.de/wp-content/uploads/2024/06/stepper_size820mm-300x300.png)
inkl. MwSt.
Produkte anzeigen| Motor Characteristics | 14-2105 | 14-2110 | 14-2115 | 14-2205 | 14-2210 | 14-2215 |
|---|---|---|---|---|---|---|
| Voltage | 6.6 V | 3.5 V | 2.7 V | 12 V | 6 V | 4 V |
| Current | 0.5 A | 1 A | 1.5 A | 0.5 A | 1 A | 1.5 A |
| Resistance | 13.2 Ω | 3.5 Ω | 1.8 Ω | 24 Ω | 6 Ω | 2.7 Ω |
| Inductance | 14 mH | 3.6 mH | 1.9 mH | 29 mH | 7.2 mH | 3.2 mH |
| Weight | 189 g | 189 g | 189 g | 210 g | 210 g | 210 g |
| Lead Wire No. | 4 | 4 | 4 | 4 | 4 | 4 |
| Motor Length | 33.6 mm | 33.6 mm | 33.6 mm | 45.6 mm | 45.6 mm | 45.6 mm |
| Size | 14 Nema | 14 Nema | 14 Nema | 14 Nema | 14 Nema | 14 Nema |
| Flange size | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm |
| Lead Screw Code | SLSLA – Size 14 [35mm] |
|---|---|
| AA, Screw Lead | 6.35 mm |
| AB, Screw Lead | 6.35 mm |
| B, Screw Lead | 6.35 mm |
| D, Screw Lead | 6.35 mm |
| F, Screw Lead | 6.35 mm |
| J, Screw Lead | 6.35 mm |
| K, Screw Lead | 6.35 mm |
| L, Screw Lead | 6.35 mm |
| Q, Screw Lead | 6.35 mm |
| R, Screw Lead | 6.35 mm |
| S, Screw Lead | 6.35 mm |
| U, Screw Lead | 6.35 mm |
| W, Screw Lead | 6.35 mm |
| Y, Screw Lead | 6.35 mm |
| Z, Screw Lead | 6.35 mm |
| M, Screw Lead | 8 mm |
| T, Screw Lead | 8 mm |
| G, Screw Lead | 8 mm |
| Specification | 14-2105 |
|---|---|
| Voltage | 6.6 V |
| Current | 0.5 A |
| Resistance | 13.2 Ω |
| Inductance | 14 mH |
| Weight | 189 g |
| Lead Wire No. | 4 |
| Motor Length | 33.6 mm |
| Size | 14 Nema |
| Flange size | 35 mm |
| Lead Screw Code | 14-2105 |
|---|---|
| AA, Screw Lead | 6.35 mm |
| AB, Screw Lead | 6.35 mm |
| B, Screw Lead | 6.35 mm |
| D, Screw Lead | 6.35 mm |
| F, Screw Lead | 6.35 mm |
| J, Screw Lead | 6.35 mm |
| K, Screw Lead | 6.35 mm |
| L, Screw Lead | 6.35 mm |
| Q, Screw Lead | 6.35 mm |
| R, Screw Lead | 6.35 mm |
| S, Screw Lead | 6.35 mm |
| U, Screw Lead | 6.35 mm |
| W, Screw Lead | 6.35 mm |
| Y, Screw Lead | 6.35 mm |
| Z, Screw Lead | 6.35 mm |
| M, Screw Lead | 8 mm |
| T, Screw Lead | 8 mm |
| G, Screw Lead | 8 mm |
| Specification | 14-2110 |
|---|---|
| Voltage | 3.5 V |
| Current | 1 A |
| Resistance | 3.5 Ω |
| Inductance | 3.6 mH |
| Weight | 189 g |
| Lead Wire No. | 4 |
| Motor Length | 33.6 mm |
| Size | 14 Nema |
| Flange size | 35 mm |
| Lead Screw Code | 14-2110 |
|---|---|
| AA, Screw Lead | 6.35 mm |
| AB, Screw Lead | 6.35 mm |
| B, Screw Lead | 6.35 mm |
| D, Screw Lead | 6.35 mm |
| F, Screw Lead | 6.35 mm |
| J, Screw Lead | 6.35 mm |
| K, Screw Lead | 6.35 mm |
| L, Screw Lead | 6.35 mm |
| Q, Screw Lead | 6.35 mm |
| R, Screw Lead | 6.35 mm |
| S, Screw Lead | 6.35 mm |
| U, Screw Lead | 6.35 mm |
| W, Screw Lead | 6.35 mm |
| Y, Screw Lead | 6.35 mm |
| Z, Screw Lead | 6.35 mm |
| M, Screw Lead | 8 mm |
| T, Screw Lead | 8 mm |
| G, Screw Lead | 8 mm |
| Specification | 14-2115 |
|---|---|
| Voltage | 2.7 V |
| Current | 1.5 A |
| Resistance | 1.8 Ω |
| Inductance | 1.9 mH |
| Weight | 189 g |
| Lead Wire No. | 4 |
| Motor Length | 33.6 mm |
| Size | 14 Nema |
| Flange size | 35 mm |
| Lead Screw Code | 14-2115 |
|---|---|
| AA, Screw Lead | 6.35 mm |
| AB, Screw Lead | 6.35 mm |
| B, Screw Lead | 6.35 mm |
| D, Screw Lead | 6.35 mm |
| F, Screw Lead | 6.35 mm |
| J, Screw Lead | 6.35 mm |
| K, Screw Lead | 6.35 mm |
| L, Screw Lead | 6.35 mm |
| Q, Screw Lead | 6.35 mm |
| R, Screw Lead | 6.35 mm |
| S, Screw Lead | 6.35 mm |
| U, Screw Lead | 6.35 mm |
| W, Screw Lead | 6.35 mm |
| Y, Screw Lead | 6.35 mm |
| Z, Screw Lead | 6.35 mm |
| M, Screw Lead | 8 mm |
| T, Screw Lead | 8 mm |
| G, Screw Lead | 8 mm |
| Specification | 14-2205 |
|---|---|
| Voltage | 12 V |
| Current | 0.5 A |
| Resistance | 24 Ω |
| Inductance | 29 mH |
| Weight | 210 g |
| Lead Wire No. | 4 |
| Motor Length | 45.6 mm |
| Size | 14 Nema |
| Flange size | 35 mm |
| Lead Screw Code | 14-2205 |
|---|---|
| AA, Screw Lead | 6.35 mm |
| AB, Screw Lead | 6.35 mm |
| B, Screw Lead | 6.35 mm |
| D, Screw Lead | 6.35 mm |
| F, Screw Lead | 6.35 mm |
| J, Screw Lead | 6.35 mm |
| K, Screw Lead | 6.35 mm |
| L, Screw Lead | 6.35 mm |
| Q, Screw Lead | 6.35 mm |
| R, Screw Lead | 6.35 mm |
| S, Screw Lead | 6.35 mm |
| U, Screw Lead | 6.35 mm |
| W, Screw Lead | 6.35 mm |
| Y, Screw Lead | 6.35 mm |
| Z, Screw Lead | 6.35 mm |
| M, Screw Lead | 8 mm |
| T, Screw Lead | 8 mm |
| G, Screw Lead | 8 mm |
| Specification | 14-2210 |
|---|---|
| Voltage | 6 V |
| Current | 1 A |
| Resistance | 6 Ω |
| Inductance | 7.2 mH |
| Weight | 210 g |
| Lead Wire No. | 4 |
| Motor Length | 45.6 mm |
| Size | 14 Nema |
| Flange size | 35 mm |
| Lead Screw Code | 14-2210 |
|---|---|
| AA, Screw Lead | 6.35 mm |
| AB, Screw Lead | 6.35 mm |
| B, Screw Lead | 6.35 mm |
| D, Screw Lead | 6.35 mm |
| F, Screw Lead | 6.35 mm |
| J, Screw Lead | 6.35 mm |
| K, Screw Lead | 6.35 mm |
| L, Screw Lead | 6.35 mm |
| Q, Screw Lead | 6.35 mm |
| R, Screw Lead | 6.35 mm |
| S, Screw Lead | 6.35 mm |
| U, Screw Lead | 6.35 mm |
| W, Screw Lead | 6.35 mm |
| Y, Screw Lead | 6.35 mm |
| Z, Screw Lead | 6.35 mm |
| M, Screw Lead | 8 mm |
| T, Screw Lead | 8 mm |
| G, Screw Lead | 8 mm |
| Specification | 14-2215 |
|---|---|
| Voltage | 4 V |
| Current | 1.5 A |
| Resistance | 2.7 Ω |
| Inductance | 3.2 mH |
| Weight | 210 g |
| Lead Wire No. | 4 |
| Motor Length | 45.6 mm |
| Size | 14 Nema |
| Flange size | 35 mm |
| Lead Screw Code | 14-2215 |
|---|---|
| AA, Screw Lead | 6.35 mm |
| AB, Screw Lead | 6.35 mm |
| B, Screw Lead | 6.35 mm |
| D, Screw Lead | 6.35 mm |
| F, Screw Lead | 6.35 mm |
| J, Screw Lead | 6.35 mm |
| K, Screw Lead | 6.35 mm |
| L, Screw Lead | 6.35 mm |
| Q, Screw Lead | 6.35 mm |
| R, Screw Lead | 6.35 mm |
| S, Screw Lead | 6.35 mm |
| U, Screw Lead | 6.35 mm |
| W, Screw Lead | 6.35 mm |
| Y, Screw Lead | 6.35 mm |
| Z, Screw Lead | 6.35 mm |
| M, Screw Lead | 8 mm |
| T, Screw Lead | 8 mm |
| G, Screw Lead | 8 mm |
