Weiterlesen| Specification | C1012F43-0045 | C1012F43-0108 | C1012F43-0113 |
|---|---|---|---|
| Voltage | 4.5 V | 2.0 V | 3.0 V |
| Terminal resistance | 3.7 Ω | 16.5 Ω | 11.1 Ω |
| No-load speed | 32000 rpm | 7000 rpm | 12900 rpm |
| No-load current | 80 mA | 20 mA | 30 mA |
| Stall torque | 1.00 mNm | 0.30 mNm | 0.50 mNm |
| Stall current | 969 mA | 120 mA | 288 mA |
| Load torque | 0.29 mNm | 0.09 mNm | 0.17 mNm |
| Load speed | 23000 rpm | 4900 rpm | 8400 rpm |
| Load current | 330 mA | 50 mA | 120 mA |
| Max. output power | 0.84 W | 0.06 W | 0.17 W |
| Max. efficiency | 46.4 % | 46.3 % | 44.7 % |
| Back-EMF constant | 0.13 mV/rpm | 0.24 mV/rpm | 0.21 mV/rpm |
| Torque constant | 1.13 mNm/A | 3.00 mNm/A | 1.94 mNm/A |
| Speed/torque gradient | 32000 rpm/mNm | 23333 rpm/mNm | 25800 rpm/mNm |
| Varistor | Yes | Yes | Yes |
| Weight | 3.15 g | 3 g | 3 g |
| Operating temperature range | -20~+80 | -20~+80 | -20~+80 |
| Specification | C1012F43-0045 |
|---|---|
| Voltage | 4.5 V |
| Terminal resistance | 3.7 Ω |
| No-load speed | 32000 rpm |
| No-load current | 80 mA |
| Stall torque | 1.00 mNm |
| Stall current | 969 mA |
| Load torque | 0.29 mNm |
| Load speed | 23000 rpm |
| Load current | 330 mA |
| Max. output power | 0.84 W |
| Max. efficiency | 46.4 % |
| Back-EMF constant | 0.13 mV/rpm |
| Torque constant | 1.13 mNm/A |
| Speed/torque gradient | 32000 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 3.15 g |
| Operating temperature range | -20~+80 °C |
| Specification | C1012F43-0108 |
|---|---|
| Voltage | 2.0 V |
| Terminal resistance | 16.5 Ω |
| No-load speed | 7000 rpm |
| No-load current | 20 mA |
| Stall torque | 0.30 mNm |
| Stall current | 120 mA |
| Load torque | 0.09 mNm |
| Load speed | 4900 rpm |
| Load current | 50 mA |
| Max. output power | 0.06 W |
| Max. efficiency | 46.3 % |
| Back-EMF constant | 0.24 mV/rpm |
| Torque constant | 3.00 mNm/A |
| Speed/torque gradient | 23333 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 3 g |
| Operating temperature range | -20~+80 °C |
| Specification | C1012F43-0113 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 11.1 Ω |
| No-load speed | 12900 rpm |
| No-load current | 30 mA |
| Stall torque | 0.50 mNm |
| Stall current | 288 mA |
| Load torque | 0.17 mNm |
| Load speed | 8400 rpm |
| Load current | 120 mA |
| Max. output power | 0.17 W |
| Max. efficiency | 44.7 % |
| Back-EMF constant | 0.21 mV/rpm |
| Torque constant | 1.94 mNm/A |
| Speed/torque gradient | 25800 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 3 g |
| Operating temperature range | -20~+80 °C |
