Name: Brushless DC Motor Electronics 2 - KOCO MOTION
SKU: Brushless DC Motor Electronics 2

Specifications	DS-BVM-FCAO/FETC	DS-BVS-FCAO/FETC
Adapted Motor	DC / BLDC / PMSM / VCM	DC / BLDC / PMSM / VCM
Current (Torque) Control	Control periodic 24KHz	Control periodic 24KHz
Velocity & Position Control	Control periodic 2KHz	Control periodic 2KHz
Reference Command	USB + CANopen or EtherCAT (CoE, FoE)	USB + CANopen or EtherCAT (CoE, FoE)
Auto Tuning	Automatic self-configuration and optimization of motor phasing, wires, current loop, velocity control loop.	Automatic self-configuration and optimization of motor phasing, wires, current loop, velocity control loop.
User Interface	GUI : DINGS’ servo studio, Setting, Drive, Motor, Feedback, I/O, Motion	GUI : DINGS’ servo studio, Setting, Drive, Motor, Feedback, I/O, Motion
Protective Functions	Under-and over-voltage, Over-current, Over-load (with PT), Drive over-temperature, Feedback sensor signal lost	Under-and over-voltage, Over-current, Over-load (with PT), Drive over-temperature, Feedback sensor signal lost
Ambient temperature	0 ~ 45	0 ~ 45
Storage Temperature	0 ~ 70	0 ~ 70
Operating Humidity	10 ~ 90% RH	10 ~ 90% RH

Nehmen Sie Kontakt auf

+49 7720 995858-0 info@kocomotion.de

Specification	DS-BVM-FCAO/FETC
Adapted Motor	DC / BLDC / PMSM / VCM
Current (Torque) Control	Control periodic 24KHz
Velocity & Position Control	Control periodic 2KHz
Reference Command	USB + CANopen or EtherCAT (CoE, FoE)
Auto Tuning	Automatic self-configuration and optimization of motor phasing, wires, current loop, velocity control loop.
User Interface	GUI : DINGS’ servo studio, Setting, Drive, Motor, Feedback, I/O, Motion
Protective Functions	Under-and over-voltage, Over-current, Over-load (with PT), Drive over-temperature, Feedback sensor signal lost
Ambient temperature	0 ~ 45 °C
Storage Temperature	0 ~ 70 °C
Operating Humidity	10 ~ 90% RH

Nehmen Sie Kontakt auf

+49 7720 995858-0 info@kocomotion.de

Specification	DS-BVS-FCAO/FETC
Adapted Motor	DC / BLDC / PMSM / VCM
Current (Torque) Control	Control periodic 24KHz
Velocity & Position Control	Control periodic 2KHz
Reference Command	USB + CANopen or EtherCAT (CoE, FoE)
Auto Tuning	Automatic self-configuration and optimization of motor phasing, wires, current loop, velocity control loop.
User Interface	GUI : DINGS’ servo studio, Setting, Drive, Motor, Feedback, I/O, Motion
Protective Functions	Under-and over-voltage, Over-current, Over-load (with PT), Drive over-temperature, Feedback sensor signal lost
Ambient temperature	0 ~ 45 °C
Storage Temperature	0 ~ 70 °C
Operating Humidity	10 ~ 90% RH

Nehmen Sie Kontakt auf

+49 7720 995858-0 info@kocomotion.de

Weiterlesen	DS-BVM-FCAO/FETC	Loggen Sie sich ein, um Preise für dieses Produkt zu sehen inkl. 19 % MwSt.
Weiterlesen	DS-BVS-FCAO/FETC	Loggen Sie sich ein, um Preise für dieses Produkt zu sehen inkl. 19 % MwSt.
