| Parameter | Unit | 11N2110 |
|---|---|---|
| Rated voltage | V | 2.2 |
| Current | A | 1 |
| Winding resistance | Ω | 2.1 |
| Inductance | mH | 1.5 |
| Lead Wire No. | 4 | |
| Motor length | mm | 33.5 |
| Motor Size | Body Length | Part Code | Stroke | Lead Code | Lead | Max. Gripping Force | Rec. Gripping Force |
|---|---|---|---|---|---|---|---|
| 28 mm | 33.5 mm | 11N2105, 11N2110 | 6 mm, 12 mm | A | 0.635 mm | 110 N | 55 N |
| 28 mm | 33.5 mm | 11N2105, 11N2110 | 6 mm, 12 mm | D | 1.27 mm | 84 N | 42 N |
| 28 mm | 33.5 mm | 11N2105, 11N2110 | 6 mm, 12 mm | K | 2.54 mm | 56 N | 28 N |
| 28 mm | 33.5 mm | 11N2105, 11N2110 | 6 mm, 12 mm | R | 5.08 mm | 36 N | 18 N |
| 28 mm | 45 mm | 11N2210, 11N2216 | 6 mm, 12 mm | A | 0.635 mm | 140 N | 70 N |
| 28 mm | 45 mm | 11N2210, 11N2216 | 6 mm, 12 mm | D | 1.27 mm | 120 N | 60 N |
| 28 mm | 45 mm | 11N2210, 11N2216 | 6 mm, 12 mm | K | 2.54 mm | 100 N | 50 N |
| 28 mm | 45 mm | 11N2210, 11N2216 | 6 mm, 12 mm | R | 5.08 mm | 60 N | 30 N |
Technische Angaben dienen als Orientierungswerte, da die einzelnen Antriebe und Motoren anwendungsbezogen konfiguriert werden. Technische und optische Änderungen vorbehalten.
