Description
Graphite Brush
| Parameter | Unit | C1723R231B-0165 |
|---|---|---|
| Voltage | V | 12 |
| No-load speed | rpm | 17200 |
| No-load current | mA | 80 |
| Stall torque | mNm | 11.77 |
| Stall current | mA | 2700 |
| Load torque | mNm | 0.49 |
| Load speed | rpm | 16500 |
| Load current | mA | 180 |
| Max output power | W | 5.31 |
| Max efficiency | % | 47.7 |
| Torque constant | mNm/A | 4.49 |
| Speed/torque gradient | rpm/mNm | 1461 |
| Varistor | Yes/No | Yes |
| Weight | g | 18.2 |
| Operating temperature range | °C | -20~+80 |
Applications
small electronic products
portable electric tools
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
