Beschreibung
SKA DDR
Stall Torque: 41,0 – 115,0 Nm
Peak Torque: 128 – 458 Nm
Maxium Speed @ 230/400 Vac: 300-750/500-800 rpm
Loggen Sie sich ein, um Preise für dieses Produkt zu sehen
SKA DDR
Stall Torque: 41,0 – 115,0 Nm
Peak Torque: 128 – 458 Nm
Maxium Speed @ 230/400 Vac: 300-750/500-800 rpm
SKA DDR
Stall Torque: 41,0 – 115,0 Nm
Peak Torque: 128 – 458 Nm
Maxium Speed @ 230/400 Vac: 300-750/500-800 rpm
Parameter | Unit | SKA DDR 245.90.93.51 | SKA DDR 245.90.93.52 | SKA DDR 245.90.93.53 |
---|---|---|---|---|
Stall torque | Nm | 93 | 93 | 93 |
Peak torque | Nm | 350 | 350 | 350 |
Stall current | Arms | 9.89 | 5.92 | 2.96 |
Peak current | Arms | 44.7 | 26.5 | 13.2 |
Maximum speed @230 Vac 3phase | rpm | 300 | 180 | 90 |
Maximum speed @400 Vac 3phase | rpm | 500 | 300 | 150 |
Torque constant ± 5% | Nm/Arms | 7.9 | 13.2 | 26.4 |
Voltage constant ± 5% | Vrms/krpm | 570 | 950 | 1900 |
Phase/phase resistance ± 5% | Ohm | 1.14 | 4.32 | 14.3 |
Phase/phase inductance | mH | 18 | 40 | 142 |
Electrical time constant | msec | 15.8 | 15.8 | 15.8 |
Thermal resistance | °C/W | 0.42 | 0.42 | 0.42 |
Family Specification | Unit | SKA DDR 245 90 |
---|---|---|
Time Rating | Continous | |
Insulation Class | F | |
Poles | 28 | |
Insulation System UL/CSA | cURus, DV155JFile nr.:E216686 | |
Ambient temperature | °C | 0 to 40 °C |
Ambient humidity | 20 to 80 %RH (non condensing) | |
Thermal protection | PT 1000 | |
CE | certified |
Family Overview | Unit | SKA DDR 245 90 |
---|---|---|
Stall Torque | Nm | 93 |
Peak Torque | Nm | 350 |
Maxium Speed @ 230/400 Vac | rpm | 90 – 300 |
Technische Angaben dienen als Orientierungswerte, da die einzelnen Antriebe und Motoren anwendungsbezogen konfiguriert werden. Technische und optische Änderungen vorbehalten.
Parameter | Unit | SKA DDR 245.90.93.51 |
---|---|---|
Stall torque | Nm | 93 |
Peak torque | Nm | 350 |
Stall current | Arms | 9.89 |
Peak current | Arms | 44.7 |
Maximum speed @230 Vac 3phase | rpm | 300 |
Maximum speed @400 Vac 3phase | rpm | 500 |
Torque constant ± 5% | Nm/Arms | 7.9 |
Voltage constant ± 5% | Vrms/krpm | 570 |
Phase/phase resistance ± 5% | Ohm | 1.14 |
Phase/phase inductance | mH | 18 |
Electrical time constant | msec | 15.8 |
Thermal resistance | °C/W | 0.42 |
Family Specification | Unit | SKA DDR 245.90.93.51 |
---|---|---|
Time Rating | Continous | |
Insulation Class | F | |
Poles | 28 | |
Insulation System UL/CSA | cURus, DV155JFile nr.:E216686 | |
Ambient temperature | °C | 0 to 40 °C |
Ambient humidity | 20 to 80 %RH (non condensing) | |
Thermal protection | PT 1000 | |
CE | certified |
Family Overview | Unit | SKA DDR 245.90.93.51 |
---|---|---|
Stall Torque | Nm | 93 |
Peak Torque | Nm | 350 |
Maxium Speed @ 230/400 Vac | rpm | 90 – 300 |
Technische Angaben dienen als Orientierungswerte, da die einzelnen Antriebe und Motoren anwendungsbezogen konfiguriert werden. Technische und optische Änderungen vorbehalten.
Parameter | Unit | SKA DDR 245.90.93.52 |
---|---|---|
Stall torque | Nm | 93 |
Peak torque | Nm | 350 |
Stall current | Arms | 5.92 |
Peak current | Arms | 26.5 |
Maximum speed @230 Vac 3phase | rpm | 180 |
Maximum speed @400 Vac 3phase | rpm | 300 |
Torque constant ± 5% | Nm/Arms | 13.2 |
Voltage constant ± 5% | Vrms/krpm | 950 |
Phase/phase resistance ± 5% | Ohm | 4.32 |
Phase/phase inductance | mH | 40 |
Electrical time constant | msec | 15.8 |
Thermal resistance | °C/W | 0.42 |
Family Specification | Unit | SKA DDR 245.90.93.52 |
---|---|---|
Time Rating | Continous | |
Insulation Class | F | |
Poles | 28 | |
Insulation System UL/CSA | cURus, DV155JFile nr.:E216686 | |
Ambient temperature | °C | 0 to 40 °C |
Ambient humidity | 20 to 80 %RH (non condensing) | |
Thermal protection | PT 1000 | |
CE | certified |
Family Overview | Unit | SKA DDR 245.90.93.52 |
---|---|---|
Stall Torque | Nm | 93 |
Peak Torque | Nm | 350 |
Maxium Speed @ 230/400 Vac | rpm | 90 – 300 |
Technische Angaben dienen als Orientierungswerte, da die einzelnen Antriebe und Motoren anwendungsbezogen konfiguriert werden. Technische und optische Änderungen vorbehalten.
Parameter | Unit | SKA DDR 245.90.93.53 |
---|---|---|
Stall torque | Nm | 93 |
Peak torque | Nm | 350 |
Stall current | Arms | 2.96 |
Peak current | Arms | 13.2 |
Maximum speed @230 Vac 3phase | rpm | 90 |
Maximum speed @400 Vac 3phase | rpm | 150 |
Torque constant ± 5% | Nm/Arms | 26.4 |
Voltage constant ± 5% | Vrms/krpm | 1900 |
Phase/phase resistance ± 5% | Ohm | 14.3 |
Phase/phase inductance | mH | 142 |
Electrical time constant | msec | 15.8 |
Thermal resistance | °C/W | 0.42 |
Family Specification | Unit | SKA DDR 245.90.93.53 |
---|---|---|
Time Rating | Continous | |
Insulation Class | F | |
Poles | 28 | |
Insulation System UL/CSA | cURus, DV155JFile nr.:E216686 | |
Ambient temperature | °C | 0 to 40 °C |
Ambient humidity | 20 to 80 %RH (non condensing) | |
Thermal protection | PT 1000 | |
CE | certified |
Family Overview | Unit | SKA DDR 245.90.93.53 |
---|---|---|
Stall Torque | Nm | 93 |
Peak Torque | Nm | 350 |
Maxium Speed @ 230/400 Vac | rpm | 90 – 300 |
Technische Angaben dienen als Orientierungswerte, da die einzelnen Antriebe und Motoren anwendungsbezogen konfiguriert werden. Technische und optische Änderungen vorbehalten.
