Beschreibung
BS8413NFL is a family of 84mm brushless DC (BLDC) motors featuring inner rotor, slotted stator construction and advanced sensorless commutation. Engineered for precision applications, these motors deliver optimal performance, superior reliability, and high power density in compact form factors.
- Key Technical Specifications:
- Voltage: 48 V (nominal)
- Speed range: 565 rpm to 2979 rpm (nominal), up to 3460 rpm (no-load)
- Torque: Up to 23 N·m (stall), with options from 1.0 to 1.5 N·m nominal torque
- Max output power: Up to 2082 W
- Efficiency: Up to 86%
- Commutation: Sensorless architecture for reduced wiring complexity
- Protection class: IP20
- Operating temperature: -40°C to +100°C
- Insulation class: Class B (with 180°C winding thermal class)
- Typical Applications:
- Collaborative and industrial robots
- Robotic joint actuators
- Industrial automation and precision motion control
- Options & Customization:
- Custom shaft lengths, special coils, and gearheads
- Selectable bearing types, Hall sensors, encoders
- Driver integration available
With a robust construction, low cogging, and flexible configuration, the BS8413NFL family is an ideal choice for engineers requiring efficiency, torque stability, and adaptable system integration in advanced automation environments.
