Description
Flange dimensions: 40 mm
Rated Output Power: 50 – 100 W
Rated Torque: 0,16 – 0,32 Nm
Rated Speed: 3000 rpm
incl. 19% VAT
Flange dimensions: 40 mm
Rated Output Power: 50 – 100 W
Rated Torque: 0,16 – 0,32 Nm
Rated Speed: 3000 rpm
Flange dimensions: 40 mm
Rated Output Power: 50 – 100 W
Rated Torque: 0,16 – 0,32 Nm
Rated Speed: 3000 rpm
Specification | TC-E 40 1B C1 2 |
---|---|
Continuous Stall Torque | 0.32 Nm |
Peak Torque | 0.96 Nm |
Nominal working Speed | 3000 rpm |
Maximum working speed | 6000 rpm |
Nominal Torque | 0.32 Nm |
Nominal Current | 0.89 Arms |
Nominal Power | 0.1 kW |
Rated winding voltage | 230 Vac |
Maximum winding voltage | 360 Vdc |
Maximum voltage to ground | 255 Vac |
Maximum current | 2.7 Arms |
Continuous Stall current | 0.81 Arms |
Voltage Constant | 24 Vrms/Krpm |
Torque Constant | 0.4 Nm/Arms |
Winding resistance | 23.4 Ω |
Winding inductance qu-v | 21.5 mH |
Winding inductance du-v | 20.6 mH |
Rotor inertia without holding brake | 0.065 kg·cm² |
Rotor inertia with holding brake | 0.066 kg·cm² |
Mass without holding brake | 0.56 Kg |
Mass with holding brake | 0.77 Kg |
Thermal time constant | 15 min |
Maximum radial shaft load | 85 N |
Maximum axial shaft load | 40 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
