MLM5 NEMA 14 with
- Pulse/Direction
- Motion Control (RS485)
- CANopen
- Ethernet (MCode, Modbus TCP, Ethernet IP, Profinet I/O)
| General Specifications | MLM5 NEMA 14 External Linear Step/direction input IP20 | MLM5 NEMA 14 Non-captive Linear Step/direction input IP20 |
|---|---|---|
| Control type | Step/direction input | Step/direction input |
| Feature set | – | – |
| P1 connector options | Wire Crimp | Wire Crimp |
| P2 connector options | IDC, Wire Crimp | IDC, Wire Crimp |
| Communications interface | SPI | SPI |
| NEMA size | 14 (36×36 mm) | 14 (36×36 mm) |
| Holding torque range | 0.13 … 0.25 | 0.13 … 0.25 |
| Temperature heatsink (short-time) | max. 85 | max. 85 |
| IP rating | IP20 | IP20 |
| Input voltage | +12 to +48 | +12 to +48 |
| Power supply current requirement | 1.0 A | 1.0 A |
| Parameter settings | MLM5 NEMA 14 External Linear Step/direction input IP20 | MLM5 NEMA 14 Non-captive Linear Step/direction input IP20 |
|---|---|---|
| Input Step, Direction & Enable voltage | – | – |
| Current | – | – |
| Digital Filter Range | 10 … 38.8 | 10 … 38.8 |
| Step Frequency | 5 MHz Max | 5 MHz Max |
| Microstep Resolutions | 200 … 51200 | 200 … 51200 |
| Clock Types | – | – |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
MLM5 NEMA 14 External Linear Step/direction input IP20
MLM5 NEMA 14 Non-captive Linear Step/direction input IP20
MLM5 NEMA 14 External Linear Step/direction input IP20
MLM5 NEMA 14 Non-captive Linear Step/direction input IP20
MLM5 NEMA 14 External Linear Step/direction input IP20
datasheet
software
MLM5 NEMA 14 Non-captive Linear Step/direction input IP20
datasheet
software
| Specification | MLM5 NEMA 14 External Linear Step/direction input IP20 |
|---|---|
| Control type | Step/direction input |
| Feature set | – |
| P1 connector options | Wire Crimp Power & I/O |
| P2 connector options | IDC, Wire Crimp Comm |
| Communications interface | SPI |
| NEMA size | 14 (36×36 mm) |
| Holding torque range | 0.13 … 0.25 Nm |
| Temperature heatsink (short-time) | max. 85 °C |
| IP rating | IP20 |
| Input voltage | +12 to +48 +VDC |
| Power supply current requirement | 1.0 A |
| Parameter settings | MLM5 NEMA 14 External Linear Step/direction input IP20 |
|---|---|
| Input Step, Direction & Enable voltage | – |
| Current | – |
| Digital Filter Range | 10 … 38.8 MHz … kHz |
| Step Frequency | 5 MHz Max |
| Microstep Resolutions | 200 … 51200 Steps/Rev |
| Clock Types | – |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
MLM5 NEMA 14 External Linear Step/direction input IP20
MLM5 NEMA 14 External Linear Step/direction input IP20
MLM5 NEMA 14 External Linear Step/direction input IP20
datasheet
software
| Specification | MLM5 NEMA 14 Non-captive Linear Step/direction input IP20 |
|---|---|
| Control type | Step/direction input |
| Feature set | – |
| P1 connector options | Wire Crimp Power & I/O |
| P2 connector options | IDC, Wire Crimp Comm |
| Communications interface | SPI |
| NEMA size | 14 (36×36 mm) |
| Holding torque range | 0.13 … 0.25 Nm |
| Temperature heatsink (short-time) | max. 85 °C |
| IP rating | IP20 |
| Input voltage | +12 to +48 +VDC |
| Power supply current requirement | 1.0 A |
| Parameter settings | MLM5 NEMA 14 Non-captive Linear Step/direction input IP20 |
|---|---|
| Input Step, Direction & Enable voltage | – |
| Current | – |
| Digital Filter Range | 10 … 38.8 MHz … kHz |
| Step Frequency | 5 MHz Max |
| Microstep Resolutions | 200 … 51200 Steps/Rev |
| Clock Types | – |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
