![SBSLA - Size 6 [14mm]](https://www.kocomotion.de/wp-content/uploads/2024/06/Ball_size614mm.png)
Produkt
incl. VAT
The size 6 is our smallest Stepper Ball Screw Linear Actuators.
External version is available.
Various screw end machining and encoder options are available.
![SBSLA - Size 6 [14mm]](https://www.kocomotion.de/wp-content/uploads/2024/06/Ball_size614mm-400x200.png)
| Motor Characteristics | 6E2103 |
|---|---|
| Voltage | 6.6 V |
| Current | 0.3 A |
| Resistance | 22 Ω |
| Inductance | 3.6 mH |
| Lead Wire No. | 4 |
| Motor Length | 30 mm |
| Size | 6 Nema |
| Flange size | 14 mm |
| Ball screw type | 0401 | 0402 |
| Ball size | Ø0.8 | Ø0.8 |
| Number of threads | 1 | 1 |
| Right | Right | Right |
| Ø3.3 | Ø3.3 | Ø3.3 |
| Number of circuits | 3.7×1 | 2.7×1 |
| Shaft nut material | SCM415H | SCM415H |
| Surface hardness | HRC58~62 | HRC58~62 |
| Anti-rust treatment | Anti-rust oil | Anti-rust oil |
| Grade | C7 | C7 |
| Nut size | A | B | C | D | H | W | X | Position accuracy | Total run out | Axial play | Dynamic load[N] | Static load[N] |
| BS0401 | 23 | 4 | 17 | 11 | 15 | 17 | 3.4 | ±0.05 | 0.12 | ≤0.03 | 560 | 790 |
| BS0402 | 23 | 4 | 19 | 11 | 15 | 17 | 3.4 | ±0.05 | 0.12 | ≤0.03 | 420 | 570 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | 6E2103 |
|---|---|
| Voltage | 6.6 V |
| Current | 0.3 A |
| Resistance | 22 Ω |
| Inductance | 3.6 mH |
| Lead Wire No. | 4 |
| Motor Length | 30 mm |
| Size | 6 Nema |
| Flange size | 14 mm |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
