Description
Precious Metal Commutation
| Specification | L1013N5M07-295-5.5 |
|---|---|
| Voltage | 5.5 V |
| Terminal resistance | 3.9 Ω |
| No-load speed | 29500 rpm |
| No-load current | 37 mA |
| Stall torque | 2.4 mNm |
| Stall current | 1421 mA |
| Load torque | 0.3 mNm |
| Load speed | 25810 rpm |
| Load current | 210 mA |
| Max. output power | 1.9 W |
| Max. efficiency | 70 % |
| Back-EMF constant | 0.2 mV/rpm |
| Torque constant | 1.7 mNm/A |
| Speed/torque gradient | 12290 rpm/mNm |
| Rotor inertia | 0.06 g·cm² |
| Weight | 4.1 g |
| Operating temperature range | -20~+65 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
