| Characteristics | L0408N3M08-750-3.4 | L0408N3M32-580-3.4 | L0408N3M12-785-5.0 | L0408N3M70-650-3.4 |
|---|---|---|---|---|
| Voltage | 3.4 V | 3.4 V | 5.0 V | 3.4 V |
| Terminal resistance | 11.0 Ω | 22.0 Ω | 25.0 Ω | 13.2 Ω |
| No-load speed | 75000 rpm | 58000 rpm | 78500 rpm | 65000 rpm |
| No-load current | 70 mA | 40 mA | 50 mA | 60 mA |
| Stall torque | 0.08 mNm | 0.05 mNm | 0.07 mNm | 0.08 mNm |
| Stall current | 309 mA | 155 mA | 200 mA | 258 mA |
| Load torque | 0.03 mNm | 0.03 mNm | 0.03 mNm | 0.03 mNm |
| Load speed | 46880 rpm | 21750 rpm | 43870 rpm | 39340 rpm |
| Load current | 160 mA | 110 mA | 120 mA | 140 mA |
| Max. output power | 0.16 W | 0.07 W | 0.14 W | 0.13 W |
| Max. efficiency | 27.5 % | 24.4 % | 24.9 % | 26.9 % |
| Back-EMF constant | 0.04 mV/rpm | 0.04 mV/rpm | 0.05 mV/rpm | 0.04 mV/rpm |
| Torque constant | 0.33 mNm/A | 0.41 mNm/A | 0.46 mNm/A | 0.38 mNm/A |
| Speed/torque gradient | 937500 rpm/mNm | 1208333 rpm/mNm | 1154412 rpm/mNm | 855263 rpm/mNm |
| Rotor inertia | 0.003 g·cm² | 0.003 g·cm² | 0.003 g·cm² | 0.003 g·cm² |
| Weight | 0.5 g | 0.5 g | 0.5 g | 0.5 g |
| Operating temperature range | -20~+65 | -20~+65 | -20~+65 | -20~+65 |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0408N3M08-750-3.4 |
|---|---|
| Voltage | 3.4 V |
| Terminal resistance | 11.0 Ω |
| No-load speed | 75000 rpm |
| No-load current | 70 mA |
| Stall torque | 0.08 mNm |
| Stall current | 309 mA |
| Load torque | 0.03 mNm |
| Load speed | 46880 rpm |
| Load current | 160 mA |
| Max. output power | 0.16 W |
| Max. efficiency | 27.5 % |
| Back-EMF constant | 0.04 mV/rpm |
| Torque constant | 0.33 mNm/A |
| Speed/torque gradient | 937500 rpm/mNm |
| Rotor inertia | 0.003 g·cm² |
| Weight | 0.5 g |
| Operating temperature range | -20~+65 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0408N3M32-580-3.4 |
|---|---|
| Voltage | 3.4 V |
| Terminal resistance | 22.0 Ω |
| No-load speed | 58000 rpm |
| No-load current | 40 mA |
| Stall torque | 0.05 mNm |
| Stall current | 155 mA |
| Load torque | 0.03 mNm |
| Load speed | 21750 rpm |
| Load current | 110 mA |
| Max. output power | 0.07 W |
| Max. efficiency | 24.4 % |
| Back-EMF constant | 0.04 mV/rpm |
| Torque constant | 0.41 mNm/A |
| Speed/torque gradient | 1208333 rpm/mNm |
| Rotor inertia | 0.003 g·cm² |
| Weight | 0.5 g |
| Operating temperature range | -20~+65 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0408N3M12-785-5.0 |
|---|---|
| Voltage | 5.0 V |
| Terminal resistance | 25.0 Ω |
| No-load speed | 78500 rpm |
| No-load current | 50 mA |
| Stall torque | 0.07 mNm |
| Stall current | 200 mA |
| Load torque | 0.03 mNm |
| Load speed | 43870 rpm |
| Load current | 120 mA |
| Max. output power | 0.14 W |
| Max. efficiency | 24.9 % |
| Back-EMF constant | 0.05 mV/rpm |
| Torque constant | 0.46 mNm/A |
| Speed/torque gradient | 1154412 rpm/mNm |
| Rotor inertia | 0.003 g·cm² |
| Weight | 0.5 g |
| Operating temperature range | -20~+65 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0408N3M70-650-3.4 |
|---|---|
| Voltage | 3.4 V |
| Terminal resistance | 13.2 Ω |
| No-load speed | 65000 rpm |
| No-load current | 60 mA |
| Stall torque | 0.08 mNm |
| Stall current | 258 mA |
| Load torque | 0.03 mNm |
| Load speed | 39340 rpm |
| Load current | 140 mA |
| Max. output power | 0.13 W |
| Max. efficiency | 26.9 % |
| Back-EMF constant | 0.04 mV/rpm |
| Torque constant | 0.38 mNm/A |
| Speed/torque gradient | 855263 rpm/mNm |
| Rotor inertia | 0.003 g·cm² |
| Weight | 0.5 g |
| Operating temperature range | -20~+65 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
