Description
6mm 3V micro planetary gearbox motor
L0616—06PP–L0615-1800-3.0-06PR25-0035
incl. 19% VAT
6mm 3V micro planetary gearbox motor
| Specification | L0616—06PP–L0615-1800-3.0-06PR25-0035 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 7.8 Ω |
| No-load speed | 1750 rpm |
| No-load current | 55 A |
| Max torque | 3.4 mNm |
| Load torque | 0.2 mNm |
| Load speed | 1680 rpm |
| Load current | 65 mA |
| Reduction ratio | 1/25 |
| Weight | 1.2 g |
| Operating temperature range | -10～+70 °C |
Applications
medical equipment
security systems and locks
audio and visual products
personal healthcare products
high-end hobby products
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
