Description
Features
1. 32-bit DSP Technology
2. Anti-Resonance for optimal torque, extra smooth motion,
low motor heating and noise
3. 3-digit dialing code adjustable, 8 output current settings
4. Power-on automatic setting, automatic current halving at rest
5. Precise current control significantly reduces motor heating
6. Support single and double pulses, dial selection
7. Drive 4,6,8-wire two-phase stepper motor
8. Optically isolated inputs
9. 70KHz max pulse input frequency
10. 8 output current settings of 0.3 – 2.2A via DIP Switches
11. Over-voltage and over-current protections
12. External alarm output, maximum output current 100mA, withstand 24Vdc
