Description
2EM3E series drives support operating modes: PP, PV, HM, CSP. The products can be matched with most of master station such as Beckhoff, Omron, Keyence, Panasonic etc.
| Parameter | 2EM3E-870 |
|---|---|
| Operation Voltage | 20-80 VDC |
| Output Current | 7 A, Peak |
| Logical Voltage | 12-24VDC VDC |
| Command Source | EtherCAT |
| # of Inputs | 2*4 |
| # of Outputs | 2*2 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
