Motor charactistics
| Parameter | Unit | 2EM3E-522 | 2EM3E-556 | 2EM3E-870 |
|---|---|---|---|---|
| Operating voltage | VDC | 20-50 | 20-50 | 20-80 |
| Output current | A, Peak | 2.2 | 5.6 | 7 |
| Logic supply voltage | VDC | 12-24VDC | 12-24VDC | 12-24VDC |
| Command Source | EtherCAT | EtherCAT | EtherCAT | |
| # of Inputs | 2*4 | 2*4 | 2*4 | |
| # of Outputs | 2*2 | 2*2 | 2*2 | |
| Motor length | mm | 155 | 155 | 155 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
PDF Downloads
2EM3E-522
drawings_2D
2EM3E-556
drawings_2D
| Parameter | Unit | 2EM3E-522 |
|---|---|---|
| Operating voltage | VDC | 20-50 |
| Output current | A, Peak | 2.2 |
| Logic supply voltage | VDC | 12-24VDC |
| Command Source | EtherCAT | |
| # of Inputs | 2*4 | |
| # of Outputs | 2*2 | |
| Motor length | mm | 155 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
PDF Downloads
2EM3E-522
drawings_2D
| Parameter | Unit | 2EM3E-556 |
|---|---|---|
| Operating voltage | VDC | 20-50 |
| Output current | A, Peak | 5.6 |
| Logic supply voltage | VDC | 12-24VDC |
| Command Source | EtherCAT | |
| # of Inputs | 2*4 | |
| # of Outputs | 2*2 | |
| Motor length | mm | 155 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
PDF Downloads
2EM3E-556
drawings_2D
| Parameter | Unit | 2EM3E-870 |
|---|---|---|
| Operating voltage | VDC | 20-80 |
| Output current | A, Peak | 7 |
| Logic supply voltage | VDC | 12-24VDC |
| Command Source | EtherCAT | |
| # of Inputs | 2*4 | |
| # of Outputs | 2*2 | |
| Motor length | mm | 155 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
