| Parameter | Unit | 14-2110 |
|---|---|---|
| Voltage | V | 3.5 |
| Current | A | 1.0 |
| Resistance | Ohm | 3.5 |
| Inductance | mH | 3.6 |
| Weight | g | 189 |
| Lead wire No. | 4 | |
| Motor length | mm | 33.6 |
Lead Screw Code
| Lead Screw Code | Unit | 14-2110 |
|---|---|---|
| AA, Screw Lead | mm | 6.35 |
| D, Screw Lead | mm | 6.35 |
| K, Screw Lead | mm | 6.35 |
| R, Screw Lead | mm | 6.35 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
