Description
Precious Metal Commutation
Precious Metal Commutation
Specification | 1025N5M02-130-6.0 |
---|---|
Voltage | 6.0 V |
Terminal resistance | 6.5 Ω |
No-load speed | 13000 rpm |
No-load current | 20 mA |
Stall torque | 3.88 mNm |
Stall current | 920 mA |
Nominal torque | 1.0 mNm |
Nominal speed | 9650 rpm |
Nominal current | 250 mA |
Max. output power | 1.32 W |
Max. efficiency | 73 % |
Back-EMF constant | 0.5 mV/rpm |
Torque constant | 4.3 mNm/A |
Speed/torque gradient | 3300 rpm/mNm |
Rotor inertia | 0.09 g·cm² |
Weight | 7.0 g |
Thermal resistance housing-ambient | 32.56 K/W |
Thermal resistance winding-housing | 36.8 K/W |
Thermal time constant motor | 113 s |
Thermal time constant winding | 90 s |
Operating temperature range | -20~+85 °C |
Thermal class of winding | 130 °C |
Axial play | ≤0.15 mm |
Radial play | 0.012 mm |
Axial load dynamic | 0.15 N |
Axial load static | 15 N |
Radial load at 3 mm from mounting face | 0.4 N |
No. of pole pairs | 1 |
Bearings | 2 sleeve bearings |
Commutator | metal 5 segments |
Protection class | 40 IP |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
