Weiterlesen| Specification | 30ZWWC65 |
|---|---|
| Pole Pairs | 2 |
| Phase Resistance | 0.5 Ω |
| Phase Inductance | 0.05 mH |
| Winding Connection | Star shape |
| Insulation Class | B |
| Duty Type | S1 |
| Feedback Method | Hall Sensors |
| Commutation Angle | 120° |
| Insulation Strength (Withstand Voltage) | 500VAC/1KHz/1mA/1s |
| Insulation Resistance | 100 MΩ/500VDC |
| Weight | 230 gr |
| Rated Voltage | 24 V |
| Rated Power | 65 W |
| Rated Torque | 90 mNm |
| Rated Speed | 6900 RPM |
| Rated Current | 3.85 A |
| No Load Speed | 9200 RPM |
| No Load Current | 0.3 A |
| Motor Efficiency | 86 % |
| Noise (Ambient noise 20db, test distance 1M) | ＜50 dB |
| Enclosure – Ambient Thermal Resistance(No Load) | 0.31 K/W |
| Motor Thermal Time Constant(No Load) | 1200 S |
| Ambient Temperature | 23 °C |
| Maximum Winding Temperature(No Load) | 43.2 °C |
| Torque Constant | 23.38 mN·m/A |
| Back-EMF Constant /Peak Value | 3.46 V/Krpm |
| Back-EMF Constant /Effective Value | 2.45 V/Krpm |
| Peak Torque | 1122.08 mNm |
| Peak Current | 48 A |
| Inertia Moment | 28 g·cm² |
| Mechanical Time Constant | 2.56 ms |
| End Cover | Stainless Steel |
| Bearing | Deep Groove Ball Bearing |
| Magnet | Sintered NdFeB |
| Shaft | Carbon Steel |
Technische Angaben dienen als Orientierungswerte, da die einzelnen Antriebe und Motoren anwendungsbezogen konfiguriert werden. Technische und optische Änderungen vorbehalten.
