Description
Precious Metal Commutation
| Parameter | VL0615N5M02-92-1.5 |
|---|---|
| Voltage | 1.5 V |
| Terminal resistance | 6.9 Ω |
| Speed | 9200 rpm |
| Current | 100 mA |
| Starting voltage | 0.8 V |
| Stall current | 220 mA |
| Weight | 2.8 g |
| Operating temperature range | -10～+65 °C |
Applications
wearable products
mobile phones
tablet PC´s
health care products
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
