| Characteristics | 1735N5C2B01-128-12.0 | 1735N5C2B02-90-24.0 |
|---|---|---|
| Voltage | 12.0 V | 24.0 V |
| Rotor resistance | 5.1 Ω | 34.5 Ω |
| No-load speed | 12800 rpm | 9000 rpm |
| No-load current | 20 mA | 10 mA |
| Stall torque | 20.7 mNm | 17.3 mNm |
| Stall current | 2350 mA | 700 mA |
| Nominal torque | 5.0 mNm | 5.0 mNm |
| Nominal speed | 9710 rpm | 6400 rpm |
| Nominal current | 580 mA | 210 mA |
| Max. output power | 6.9 W | 4.1 W |
| Max. efficiency | 82 % | 78 % |
| Back-EMF constant | 0.9 mV/rpm | 2.6 mV/rpm |
| Torque constant | 8.9 mNm/A | 25.1 mNm/A |
| Speed/torque gradient | 620 rpm/mNm | 520 rpm/mNm |
| Rotor inertia | 0.95 g·cm² | 0.95 g·cm² |
| Weight | 34 g | 34 g |
| Thermal resistance housing-ambient | 25.7 K/W | 25.7 K/W |
| Thermal resistance winding-housing | 30.4 K/W | 30.4 K/W |
| Thermal time constant motor | 245 rpm | 245 rpm |
| Thermal time constant winding | 232 s | 232 s |
| Operating temperature range | -20~+85 | -20~+85 |
| Thermal class of winding | 130 °C | 130 °C |
| Axial play | 0.01~0.15 | 0.01~0.15 |
| Radial play | 0.025 mm | 0.025 mm |
| Axial load dynamic | 2.2 N | 2.2 N |
| Axial load static | 30 N | 30 N |
| Radial load at 3 mm from mounting face | 8 N | 8 N |
| No. of pole pairs | 1 | 1 |
| Bearings | 2 ball bearings | 2 ball bearings |
| Commutator | metal 5 segments | metal 5 segments |
| Protection class | 30 IP | 30 IP |
Applications
medical equipment and devices
healthcare products
automotive
robotics
industrial automation
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
1735N5C2B
| Specification | 1735N5C2B01-128-12.0 |
|---|---|
| Voltage | 12.0 V |
| Rotor resistance | 5.1 Ω |
| No-load speed | 12800 rpm |
| No-load current | 20 mA |
| Stall torque | 20.7 mNm |
| Stall current | 2350 mA |
| Nominal torque | 5.0 mNm |
| Nominal speed | 9710 rpm |
| Nominal current | 580 mA |
| Max. output power | 6.9 W |
| Max. efficiency | 82 % |
| Back-EMF constant | 0.9 mV/rpm |
| Torque constant | 8.9 mNm/A |
| Speed/torque gradient | 620 rpm/mNm |
| Rotor inertia | 0.95 g·cm² |
| Weight | 34 g |
| Thermal resistance housing-ambient | 25.7 K/W |
| Thermal resistance winding-housing | 30.4 K/W |
| Thermal time constant motor | 245 rpm |
| Thermal time constant winding | 232 s |
| Operating temperature range | -20~+85 °C |
| Thermal class of winding | 130 °C |
| Axial play | 0.01~0.15 mm |
| Radial play | 0.025 mm |
| Axial load dynamic | 2.2 N |
| Axial load static | 30 N |
| Radial load at 3 mm from mounting face | 8 N |
| No. of pole pairs | 1 |
| Bearings | 2 ball bearings |
| Commutator | metal 5 segments |
| Protection class | 30 IP |
Applications
medical equipment and devices
healthcare products
automotive
robotics
industrial automation
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
1735N5C2B
| Specification | 1735N5C2B02-90-24.0 |
|---|---|
| Voltage | 24.0 V |
| Rotor resistance | 34.5 Ω |
| No-load speed | 9000 rpm |
| No-load current | 10 mA |
| Stall torque | 17.3 mNm |
| Stall current | 700 mA |
| Nominal torque | 5.0 mNm |
| Nominal speed | 6400 rpm |
| Nominal current | 210 mA |
| Max. output power | 4.1 W |
| Max. efficiency | 78 % |
| Back-EMF constant | 2.6 mV/rpm |
| Torque constant | 25.1 mNm/A |
| Speed/torque gradient | 520 rpm/mNm |
| Rotor inertia | 0.95 g·cm² |
| Weight | 34 g |
| Thermal resistance housing-ambient | 25.7 K/W |
| Thermal resistance winding-housing | 30.4 K/W |
| Thermal time constant motor | 245 rpm |
| Thermal time constant winding | 232 s |
| Operating temperature range | -20~+85 °C |
| Thermal class of winding | 130 °C |
| Axial play | 0.01~0.15 mm |
| Radial play | 0.025 mm |
| Axial load dynamic | 2.2 N |
| Axial load static | 30 N |
| Radial load at 3 mm from mounting face | 8 N |
| No. of pole pairs | 1 |
| Bearings | 2 ball bearings |
| Commutator | metal 5 segments |
| Protection class | 30 IP |
Applications
medical equipment and devices
healthcare products
automotive
robotics
industrial automation
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
