Produkt
incl. VAT
MFI3 MicroDrive with
- Pulse/Direction
- Motion Control (RS485)
- CANopen
- Ethernet (MCode, Modbus TCP, Ethernet IP, Profinet I/O)
incl. VAT
MFI3 MicroDrive with
General Specifications | MFI3 MicroDrive Programmable Motion Control | MFI3 MicroDrive CANopen |
---|---|---|
Control type | Programmable Motion | CANopen |
Control interface | Step, direction and enable inputs | Step, direction and enable inputs |
Driver type | Microstepping | Microstepping |
Operating temperature | 2 °C | 2 °C |
Input voltage | +12 to +48 | +12 to +48 |
Output voltage | 3.0 A | 3.0 A |
Motion step frequency | 2.5 MHz max | 2.5 MHz max |
Motion step resolutions | 1 … 256 | 1 … 256 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | MFI3 MicroDrive Programmable Motion Control |
---|---|
Control type | Programmable Motion |
Control interface | Step, direction and enable inputs |
Driver type | Microstepping |
Operating temperature | 2 °C |
Input voltage | +12 to +48 +VDC |
Output voltage | 3.0 A |
Motion step frequency | 2.5 MHz max |
Motion step resolutions | 1 … 256 steps/full step |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | MFI3 MicroDrive CANopen |
---|---|
Control type | CANopen |
Control interface | Step, direction and enable inputs |
Driver type | Microstepping |
Operating temperature | 2 °C |
Input voltage | +12 to +48 +VDC |
Output voltage | 3.0 A |
Motion step frequency | 2.5 MHz max |
Motion step resolutions | 1 … 256 steps/full step |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
