| Characteristics | B1635N2B01-450-12.0 | B1635N2B02-200-24.0 | B1635N2B03-120-3.7 |
|---|---|---|---|
| Voltage | 12.0 V | 24 V | 3.7 V |
| Terminal resistance | 0.35 Ω | 11.6 Ω | 0.7 Ω |
| No-load speed | 45000 rpm | 20000 rpm | 12000 rpm |
| No-load current | 0.35 A | 0.2 A | 0.2 A |
| Stall torque | 85 mNm | 19.3 mNm | 14.4 mNm |
| Stall current | 34 A | 2 A | 5.2 A |
| Nominal torque | 1.5 mNm | 1.5 mNm | 1.5 mNm |
| Nominal speed | 43800 rpm | 18000 rpm | 10000 rpm |
| Nominal current | 0.96 A | 0.35 A | 0.75 A |
| Max. output power | 100 W | 10 W | 4.5 W |
| Max. efficiency | 81 % | 47.0 % | 64.8 % |
| Back-EMF constant | 0.3 mV/rpm | 1.00 mV/rpm | 0.29 mV/rpm |
| Torque constant | 2.5 mNm/A | 10.3 mNm/A | 2.8 mNm/A |
| KV Value | 3750 rpm/V | 833 rpm/V | 3242 rpm/V |
| Speed/torque gradient | 530 rpm/mNm | 1033 rpm/mNm | 832 rpm/mNm |
| Rotor inertia | 1.5 gcm² | 1.5 gcm² | 1.5 gcm² |
| Weight | 40 g | 40 g | 40 g |
| Thermal resistance housing-ambient | 17 K/W | 17 K/W | 17 K/W |
| Thermal resistance winding-housing | 4.8 K/W | 4.8 K/W | 4.8 K/W |
| Thermal time constant motor | 250 s | 250 s | 250 s |
| Thermal time constant winding | 6 s | 6 s | 6 s |
| Operating temperature range | -40~+120 | -40~+120 | -40~+120 |
| Thermal class of winding | 155 °C | 155 °C | 155 °C |
| Axial play | 0.012 mm | 0.012 mm | 0.012 mm |
| Radial play | 0.008 mm | 0.008 mm | 0.008 mm |
| Axial load dynamic | 1.5 N | 1.5 N | 1.5 N |
| Axial load static | 37 N | 37 N | 37 N |
| Radial load at 3 mm from mounting face | 12 N | 12 N | 12 N |
| No. of pole pairs | 1 | 1 | 1 |
| Bearings | 2 ball bearings | 2 ball bearings | 2 ball bearings |
| Protection class | 20 IP | 20 IP | 20 IP |
| Commutation | Sensorless | Sensorless | Sensorless |
Applications
industrial automation
medical equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | B1635N2B01-450-12.0 |
|---|---|
| Voltage | 12.0 V |
| Terminal resistance | 0.35 Ω |
| No-load speed | 45000 rpm |
| No-load current | 0.35 A |
| Stall torque | 85 mNm |
| Stall current | 34 A |
| Nominal torque | 1.5 mNm |
| Nominal speed | 43800 rpm |
| Nominal current | 0.96 A |
| Max. output power | 100 W |
| Max. efficiency | 81 % |
| Back-EMF constant | 0.3 mV/rpm |
| Torque constant | 2.5 mNm/A |
| KV Value | 3750 rpm/V |
| Speed/torque gradient | 530 rpm/mNm |
| Rotor inertia | 1.5 gcm² |
| Weight | 40 g |
| Thermal resistance housing-ambient | 17 K/W |
| Thermal resistance winding-housing | 4.8 K/W |
| Thermal time constant motor | 250 s |
| Thermal time constant winding | 6 s |
| Operating temperature range | -40~+120 °C |
| Thermal class of winding | 155 °C |
| Axial play | 0.012 mm |
| Radial play | 0.008 mm |
| Axial load dynamic | 1.5 N |
| Axial load static | 37 N |
| Radial load at 3 mm from mounting face | 12 N |
| No. of pole pairs | 1 |
| Bearings | 2 ball bearings |
| Protection class | 20 IP |
| Commutation | Sensorless |
Applications
industrial automation
medical equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | B1635N2B02-200-24.0 |
|---|---|
| Voltage | 24 V |
| Terminal resistance | 11.6 Ω |
| No-load speed | 20000 rpm |
| No-load current | 0.2 A |
| Stall torque | 19.3 mNm |
| Stall current | 2 A |
| Nominal torque | 1.5 mNm |
| Nominal speed | 18000 rpm |
| Nominal current | 0.35 A |
| Max. output power | 10 W |
| Max. efficiency | 47.0 % |
| Back-EMF constant | 1.00 mV/rpm |
| Torque constant | 10.3 mNm/A |
| KV Value | 833 rpm/V |
| Speed/torque gradient | 1033 rpm/mNm |
| Rotor inertia | 1.5 gcm² |
| Weight | 40 g |
| Thermal resistance housing-ambient | 17 K/W |
| Thermal resistance winding-housing | 4.8 K/W |
| Thermal time constant motor | 250 s |
| Thermal time constant winding | 6 s |
| Operating temperature range | -40~+120 °C |
| Thermal class of winding | 155 °C |
| Axial play | 0.012 mm |
| Radial play | 0.008 mm |
| Axial load dynamic | 1.5 N |
| Axial load static | 37 N |
| Radial load at 3 mm from mounting face | 12 N |
| No. of pole pairs | 1 |
| Bearings | 2 ball bearings |
| Commutation | Sensorless |
| Protection class | 20 IP |
Applications
industrial automation
medical equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | B1635N2B03-120-3.7 |
|---|---|
| Voltage | 3.7 V |
| Terminal resistance | 0.7 Ω |
| No-load speed | 12000 rpm |
| No-load current | 0.2 A |
| Stall torque | 14.4 mNm |
| Stall current | 5.2 A |
| Nominal torque | 1.5 mNm |
| Nominal speed | 10000 rpm |
| Nominal current | 0.75 A |
| Max. output power | 4.5 W |
| Max. efficiency | 64.8 % |
| Back-EMF constant | 0.29 mV/rpm |
| Torque constant | 2.8 mNm/A |
| KV Value | 3242 rpm/V |
| Speed/torque gradient | 832 rpm/mNm |
| Rotor inertia | 1.5 gcm² |
| Weight | 40 g |
| Thermal resistance housing-ambient | 17 K/W |
| Thermal resistance winding-housing | 4.8 K/W |
| Thermal time constant motor | 250 s |
| Thermal time constant winding | 6 s |
| Operating temperature range | -40~+120 °C |
| Thermal class of winding | 155 °C |
| Axial play | 0.012 mm |
| Radial play | 0.008 mm |
| Axial load dynamic | 1.5 N |
| Axial load static | 37 N |
| Radial load at 3 mm from mounting face | 12 N |
| No. of pole pairs | 1 |
| Bearings | 2 ball bearings |
| Commutation | Sensorless |
| Protection class | 20 IP |
Applications
industrial automation
medical equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
