| Motor Characteristics | S25-112503H-7054 |
|---|---|
| Contant Current | 3 A |
| Peak Current(10s) | 4.5 A |
| Input Voltage Range | 11~25 |
| Size | 99*72*25 |
| Speed Control Signal | Analog Voltage/PWM |
| Overload Protection | Yes |
| Blockage Protection | No |
| Thermal Overload Protection | Yes |
| Inverse-polarity Protection | Yes |
| Sense of Direction | Optional |
| Enable | Optional |
| Speed Feedback Output (6 Pulses*Pole Pairs) | Optional |
| Operating Temperature | – |
| Sensored/Sensorless | Sensored |
Applications
blowers
electric tools
pumps
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | S25-112503H-7054 |
|---|---|
| Contant Current | 3 A |
| Peak Current(10s) | 4.5 A |
| Input Voltage Range | 11~25 V |
| Size | 99*72*25 mm |
| Speed Control Signal | Analog Voltage/PWM |
| Overload Protection | Yes |
| Blockage Protection | No |
| Thermal Overload Protection | Yes |
| Inverse-polarity Protection | Yes |
| Sense of Direction | Optional |
| Enable | Optional |
| Speed Feedback Output (6 Pulses*Pole Pairs) | Optional |
| Operating Temperature | – |
| Sensored/Sensorless | Sensored |
Applications
blowers
electric tools
pumps
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
