MLI1 NEMA 17 External Linear CANopen IP20

MLI1 NEMA 17 with

  • Pulse/Direction
  • Motion Control (RS485)
  • CANopen
  • Ethernet (MCode, Modbus TCP, Ethernet IP, Profinet I/O)
SKU: MLI1 NEMA 17 External Linear CANopen IP20 Category:

Description

MDrive Plus NEMA size 17 (42 mm) integrated stepper motor linear actuator. This is a CANopen CAN bus 2.0b supporting CiA301 and CiA402.
Holding torque range oz-in (N-cm): 23 … 53 (23 … 53)
I/O connector options: Flying Leads, Pluggable
Com connector: IDC, DB9
