Description
Precious Metal Commutation
| Specification | L8.520N7M11-240-3.0 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 0.83 Ω |
| No-load speed | 23650 rpm |
| No-load current | 90 mA |
| Stall torque | 4.2 mNm |
| Stall current | 3610 mA |
| Load torque | 0.5 mNm |
| Load speed | 20810 rpm |
| Load current | 510 mA |
| Max. output power | 2.58 W |
| Max. efficiency | 71.1 % |
| Back-EMF constant | 0.12 mV/rpm |
| Torque constant | 1.18 mNm/A |
| Speed/torque gradient | 5681 rpm/mNm |
| Rotor inertia | 0.07 g·cm² |
| Weight | 4.87 g |
| Operating temperature range | -20~+120 °C |
Applications
mini UAV´s
remote control hobby products
small household appliances
