Description
Precious Metal Commutation
| Specification | L1515N5M13-250-12.0 |
|---|---|
| Voltage | 12 V |
| Terminal resistance | 7.7 Ω |
| No-load speed | 25000 rpm |
| No-load current | 35 mA |
| Stall torque | 6.8 mNm |
| Stall current | 1558 mA |
| Load torque | 1.0 mNm |
| Load speed | 21340 rpm |
| Load current | 260 mA |
| Max. output power | 4.5 W |
| Max. efficiency | 72 % |
| Back-EMF constant | 0.47 mV/rpm |
| Torque constant | 4.48 mNm/A |
| Speed/torque gradient | 3660 rpm/mNm |
| Rotor inertia | 0.7 g·cm² |
| Weight | 12 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
