Description
Precious Metal Commutation
| Specification | L0816N5M13-430-6.0 |
|---|---|
| Voltage | 6.0 V |
| Terminal resistance | 5.1 Ω |
| No-load speed | 43000 rpm |
| No-load current | 60 mA |
| Stall torque | 1.4 mNm |
| Stall current | 1180 mA |
| Load torque | 0.5 mNm |
| Load speed | 27770 rpm |
| Load current | 460 mA |
| Max. output power | 1.59 W |
| Max. efficiency | 59.9 % |
| Back-EMF constant | 0.13 mV/rpm |
| Torque constant | 1.26 mNm/A |
| Speed/torque gradient | 30453 rpm/mNm |
| Rotor inertia | 0.07 g·cm² |
| Weight | 3.1 g |
| Operating temperature range | -20~+80 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
