Description
The ELD2-CAN7005B servo drive can be controlled over CANopen. This servo drive operates in Profile Position, Profile velocity, Profile Torque, or Homing mode.
| Parameter | ELD2-CAN7005B |
|---|---|
| Input Voltage | 24~70VDC |
| Rated Power | 100 W |
| Rated Current | 5 Arms |
| Peak Current | 21 Arms |
| Command Source | CANopen |
| # of Inputs | 4 |
| # of Outputs | 2 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
