Flange dimensions: 60 mm
Rated Output Power: 190 – 370 W
Rated Torque: 0,6 – 1,17 Nm
Rated Speed: 3000 rpm
Fieldbus: CanOpen
Flange dimensions: 60 mm
Rated Output Power: 190 – 370 W
Rated Torque: 0,6 – 1,17 Nm
Rated Speed: 3000 rpm
Fieldbus: CanOpen
| Specification | DUET 60 0,65 01 |
|---|---|
| Rated Voltage | 48 Vdc |
| Auxiliary Voltage (+6% -10%) | 24 Vdc |
| Minimum Voltage | 9 Vdc |
| Maximum Voltage | 60 Vdc |
| Stall Torque | 0.57 Nm |
| Stall Torque Intermittent duty S2 10″/40″ | – |
| Stall Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | – |
| Peak Torque | 1.95 Nm |
| Rated Torque | 0.6 Nm |
| Rated Torque Intermittent duty S2 10″/40″ | – |
| Rated Output Power | 190 W |
| Rated Output Power Intermittent duty S2 10″/40″ | – |
| Stall Current | 6 Arms |
| Stall Current Intermittent duty S2 10″/40″ | – |
| Peak Current | 20.7 Arms |
| Rated Current | 6.5 Arms |
| Rated Current Intermittent duty S2 10″/40″ | – |
| Rated Speed @48Vdc | 3000 rpm |
| Maximum Speed @48Vdc | 5000 rpm |
| Maximum Speed @24Vdc | 2600 rpm |
| Torque Constant (± 5%) | 0.094 Nm/Arms |
| Voltage Constant (± 5%) | 5.7 Vrms/Krpm |
| Phase/phase resistance (± 10%@25°C) | 0.38 Ω |
| Phase/phase inductance (± 10%) | 0.9 mH |
| Electrical time constant | 2.4 ms |
| Thermal Resistance | 1.9 °C/W |
| Mechanical time constant | 0.83 ms |
| Rotor Inertia without brake and without feedback | 0.13 kg·cm² |
| Duet weight | 1.2 Kg |
| Duet weight with brake | 1.6 Kg |
| Axial Load applied on the shaft’s center | 70 N |
| Radial Load applied on the shaft’s center | 220 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
