Description
Precious Metal Commutation
| Specification | C2430R23-0021 |
|---|---|
| Voltage | 24.0 V |
| Terminal resistance | 260 Ω |
| No-load speed | 2500 rpm |
| No-load current | 4 mA |
| Stall torque | 6.53 mNm |
| Stall current | 107 mA |
| Load torque | 1.96 mNm |
| Load speed | 1750 rpm |
| Load current | 35 mA |
| Max. output power | 0.34 W |
| Max. efficiency | 46.7 % |
| Back-EMF constant | 9.18 mV/rpm |
| Torque constant | 63.19 mNm/A |
| Speed/torque gradient | 383 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 48.5 g |
| Operating temperature range | -20～+80 °C |
Applications
security equipment
small electronic products
remote control model aircraft
personal care products
portable electric tools
