Description
Graphite Brush
| Specification | C2032F41-0159 |
|---|---|
| Voltage | 12.0 V |
| No-load speed | 8700 rpm |
| No-load current | 57 mA |
| Stall torque | 12.4 mNm |
| Stall current | 1101 mA |
| Load torque | 1.57 mNm |
| Load speed | 7600 rpm |
| Load current | 189 mA |
| Max. output power | 2.83 W |
| Max. efficiency | 56.9 % |
| Torque constant | 11.89 mNm/A |
| Speed/torque gradient | 701 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 33 g |
| Operating temperature range | 0~+60 °C |
Applications
small electronic products
portable electric tools
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
