Description
Graphite Brush
| Specification | C1718R231B-13120 |
|---|---|
| Voltage | 4.8 V |
| No-load speed | 14200 rpm |
| No-load current | 130 mA |
| Stall torque | 4.90 mNm |
| Stall current | 1600 mA |
| Load torque | 0.88 mNm |
| Load speed | 11600 rpm |
| Load current | 400 mA |
| Max output power | 1.82 W |
| Max efficiency | 57.5 % |
| Torque constant | 3.33 mNm/A |
| Speed/torque gradient | 2898 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 12.8 g |
| Operating temperature range | -20~+80 °C |
Applications
small electronic products
portable electric tools
