Description
13mm Planetary Gearbox Series provides advanced motion control for miniature electromechanical applications where space, durability, and accuracy are critical. Designed with a metal shell and CNC-processed metal gears, this gearbox series delivers robust performance and extended service life in demanding environments.
- Technical Specifications:
- Diameter: 13mm, available in up to 6 reduction stages
- Reduction ratios range: 4:1 (1-stage) to 4096:1 (6-stage)
- Max. rated torque: 80–200 mNm
- Max. momentary torque: 240–600 mNm
- Lengths from 10.3 mm (1-stage) to 26.8 mm (6-stage)
- Metal housing ensures robust structural integrity
- Precision gears manufactured with advanced CNC technology
- Key Applications:
- Medical equipment requiring compact high-torque drives
- Scientific instrumentation for precision motion control
- Industrial automation and specialized robotics systems
- Configurable Options:
- Custom lead wire lengths
- Variable shaft lengths
- Special coil configurations for tailored performance
This series is engineered to deliver stable power transmission and high efficiency in size-constrained applications, making it an ideal solution for OEM designers and system integrators seeking reliable miniature gearbox systems.
