Description
Precious Metal Commutation
| Parameter | Unit | VL0716N5M61-130-3.0 |
|---|---|---|
| Voltage | V | 3.0 |
| Terminal resistance | Ohm | 5.6 |
| Speed | rpm | 13000 |
| Current | mA | 180 |
| Starting voltage | V | 0.8 |
| Stall current | mA | 500 |
| Weight | g | 4 |
| Operating temperature range | °C | -10～+80 |
Applications
wearable products
mobile phones
tablet PC´s
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
