Description
SKA DDR
Stall Torque: 8,0 – 48 Nm
Peak Torque: 35 – 260 Nm
Maxium Speed @ 230/400 Vac: 750-1000/800-1000 rpm
SKA DDR
Stall Torque: 8,0 – 48 Nm
Peak Torque: 35 – 260 Nm
Maxium Speed @ 230/400 Vac: 750-1000/800-1000 rpm
SKA DDR
Stall Torque: 8,0 – 48 Nm
Peak Torque: 35 – 260 Nm
Maxium Speed @ 230/400 Vac: 750-1000/800-1000 rpm
Parameter | Unit | SKA DDR 148.240.48.52 |
---|---|---|
Stall torque | Nm | 48 |
Peak torque | Nm | 260 |
Stall current | Arms | 3.05 |
Peak current | Arms | 20.5 |
Maximum speed @230 Vac 3phase | rpm | 180 |
Maximum speed @400 Vac 3phase | rpm | 300 |
Torque constant ± 5% | Nm/Arms | 12.7 |
Voltage constant ± 5% | Vrms/krpm | 950 |
Phase/phase resistance ± 5% | Ohm | 11.6 |
Phase/phase inductance | mH | 75.5 |
Electrical time constant | msec | 6.5 |
Thermal resistance | °C/W | 0.46 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
