Description
SKA DDR
Stall Torque: 8,0 – 48 Nm
Peak Torque: 35 – 260 Nm
Maxium Speed @ 230/400 Vac: 750-1000/800-1000 rpm
incl. 19% VAT
SKA DDR
Stall Torque: 8,0 – 48 Nm
Peak Torque: 35 – 260 Nm
Maxium Speed @ 230/400 Vac: 750-1000/800-1000 rpm
SKA DDR
Stall Torque: 8,0 – 48 Nm
Peak Torque: 35 – 260 Nm
Maxium Speed @ 230/400 Vac: 750-1000/800-1000 rpm
Specification | SKA DDR 148.150.30.19 |
---|---|
Stall torque | 30 Nm |
Peak torque | 170 Nm |
Stall current | 7.5 Arms |
Peak current | 53 Arms |
Maximum speed @230 Vac 3phase | 750 rpm |
Maximum speed @400 Vac 3phase | – |
Torque constant ± 5% | 3.2 Nm/Arms |
Voltage constant ± 5% | 240 Vrms/krpm |
Phase/phase resistance ± 5% | 1.17 Ω |
Phase/phase inductance | 6.4 mH |
Electrical time constant | 5.5 msec |
Thermal resistance | 0.72 °C/W |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
