The size 14 [35mm] External Stepper Ball Screw Linear Actuator.
Various screw end machining, encoders and power-off brake options are available.
![SBSLA - Size 14 [35mm]](https://www.kocomotion.de/wp-content/uploads/2024/06/Ball_size1435mm-400x200.png)
| Motor Characteristics | 14E2110 | 14E2115 | 14E2210 | 14E2215 |
|---|---|---|---|---|
| Voltage | 3.5 V | 2.7 V | 6.0 V | 4.0 V |
| Current | 1.0 A | 1.5 A | 1.0 A | 1.5 A |
| Resistance | 3.5 Ω | 1.8 Ω | 6.0 Ω | 2.7 Ω |
| Inductance | 3.6 mH | 1.9 mH | 7.2 mH | 3.2 mH |
| Motor Length | 33.6 mm | 33.6 mm | 45.6 mm | 45.6 mm |
| Lead Wire No. | 4 | 4 | 4 | 4 |
| Size | 14 Nema | 14 Nema | 14 Nema | 14 Nema |
| Flange size | 35 mm | 35 mm | 35 mm | 35 mm |
| Ball screw type | 0601 | 0602 | 0606 | 0610 | 0801 | 0802 | 0802.5 | 0805 | 0808 | 0810 | 0812 |
| Ball size | Ø0.8 | Ø0.8 | Ø0.8 | Ø1.2 | Ø0.8 | Ø1.5875 | Ø1.5875 | Ø1.5875 | Ø1.5875 | Ø1.5875 | Ø1.5875 |
| Number of threads | 1 | 1 | 2 | 2 | 1 | 1 | 1 | 1 | 2 | 2 | 2 |
| Thread direction | Right | Right | Right | Right | Right | Right | Right | Right | Right | Right | Right |
| Shaft root dia. | Ø5.3 | Ø5.1 | Ø5.2 | Ø5.0 | Ø7.3 | Ø6.6 | Ø6.3 | Ø6.6 | Ø6.7 | Ø6.7 | Ø6.7 |
| Number of circuits | 3.7×1 | 2.7×1 | 1.6×2 | 1.2×2 | 3.7×1 | 3.7×1 | 2.7×1 | 2.7×1 | 1.6×2 | 1.6×2 | 1.6×2 |
| Shaft nut material | SCM415H | SCM415H | SCM415H | SCM415H | SCM415H | SCM415H | SCM415H | SCM415H | SCM415H | SCM415H | SCM415H |
| Surface hardness | HRC58~62 | HRC58~62 | HRC58~62 | HRC58~62 | HRC58~62 | HRC58~62 | HRC58~62 | HRC58~62 | HRC58~62 | HRC58~62 | HRC58~62 |
| Anti-rust treatment | Anti-rust oil | Anti-rust oil | Anti-rust oil | Anti-rust oil | Anti-rust oil | Anti-rust oil | Anti-rust oil | Anti-rust oil | Anti-rust oil | Anti-rust oil | Anti-rust oil |
| Grade | C7 | C7 | C7 | C7 | C7 | C7 | C7 | C7 | C7 | C7 | C7 |
| Nut size | A | B | C | D | H | W | X | E | Position accuracy | Total run out | Axial play | Dynamic load[N] | Static load[N] |
| BS0601 | 26 | 4 | 17 | 13 | 16 | 20 | 3.4 | ±0.05 | 0.12 | ≤0.03 | 680 | 1200 | |
| BS0602 | 28 | 4 | 17 | 15 | 19 | 22 | 3.4 | ±0.05 | 0.12 | ≤0.03 | 750 | 1450 | |
| BS0606 | 27 | 4 | 17 | 14 | 16 | 21 | 3.4 | 5 | ±0.05 | 0.12 | ≤0.03 | 870 | 1600 |
| BS0610 | 27 | 4 | 23 | 14 | 16 | 21 | 3.4 | 7.5 | ±0.05 | 0.12 | ≤0.03 | 950 | 1650 |
| BS0801 | 29 | 4 | 17 | 16 | 18 | 23 | 3.4 | ±0.05 | 0.12 | ≤0.03 | 780 | 1650 | |
| BS0802 | 37 | 5 | 24 | 20 | 22 | 29 | 4.5 | ±0.05 | 0.12 | ≤0.03 | 2400 | 4100 | |
| BS0802.5 | 29 | 4 | 16 | 16 | 18 | 23 | 3.4 | ±0.05 | 0.12 | ≤0.03 | 1850 | 3000 | |
| BS0805 | 31 | 4 | 28 | 18 | 20 | 25 | 3.4 | ±0.05 | 0.12 | ≤0.03 | 1850 | 3000 | |
| BS0808 | 31 | 4 | 20 | 18 | 20 | 25 | 3.4 | 6 | ±0.05 | 0.12 | ≤0.03 | 2200 | 3800 |
| BS0810 | 31 | 4 | 20 | 18 | 20 | 25 | 3.4 | 7 | ±0.05 | 0.12 | ≤0.03 | 2200 | 3800 |
| BS0812 | 31 | 4 | 24 | 18 | 20 | 25 | 3.4 | 6 | ±0.05 | 0.12 | ≤0.03 | 2200 | 3800 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | 14E2110 |
|---|---|
| Voltage | 3.5 V |
| Current | 1.0 A |
| Resistance | 3.5 Ω |
| Inductance | 3.6 mH |
| Motor Length | 33.6 mm |
| Lead Wire No. | 4 |
| Size | 14 Nema |
| Flange size | 35 mm |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | 14E2115 |
|---|---|
| Voltage | 2.7 V |
| Current | 1.5 A |
| Resistance | 1.8 Ω |
| Inductance | 1.9 mH |
| Motor Length | 33.6 mm |
| Lead Wire No. | 4 |
| Size | 14 Nema |
| Flange size | 35 mm |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | 14E2210 |
|---|---|
| Voltage | 6.0 V |
| Current | 1.0 A |
| Resistance | 6.0 Ω |
| Inductance | 7.2 mH |
| Motor Length | 45.6 mm |
| Lead Wire No. | 4 |
| Size | 14 Nema |
| Flange size | 35 mm |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | 14E2215 |
|---|---|
| Voltage | 4.0 V |
| Current | 1.5 A |
| Resistance | 2.7 Ω |
| Inductance | 3.2 mH |
| Motor Length | 45.6 mm |
| Lead Wire No. | 4 |
| Size | 14 Nema |
| Flange size | 35 mm |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
