Produkt
incl. VAT
Flange dimensions: 80 mm
Rated Output Power: 390 – 520 W
Rated Torque: 1,5 – 2,0 Nm
Rated Speed: 2500 rpm
Fieldbus: CanOpen/Ethercat
| Specification | DUET FLEXI 80 1,5 03 | DUET FLEXI 80 2 03 |
|---|---|---|
| Rated Voltage | 48 Vdc | 48 Vdc |
| Auxiliary Voltage (+6% -10%) | 24 Vdc | 24 Vdc |
| Minimum Voltage | 24 Vdc | 24 Vdc |
| Maximum Voltage | 60 Vdc | 60 Vdc |
| Stall Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 1.5 Nm | 2 Nm |
| Peak Torque | 4.5 Nm | 5.6 Nm |
| Rated Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 1.5 Nm | 2 Nm |
| Rated output power @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 390 W | 520 W |
| Rated output Power @ 10 Arms | 360 W | 360 W |
| Stall current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 10.7 Arms | 14.2 Arms |
| Peak Current | 32 Arms | 39.8 Arms |
| Rated current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 11 Arms | 14.7 Arms |
| Rated Speed @48Vdc | 2500 rpm | 2500 rpm |
| Maximum Speed @48Vdc | 3600 rpm | 3600 rpm |
| Maximum Speed @24Vdc | 1800 rpm | 1800 rpm |
| Torque Constant (± 5%) | 0.141 Nm/Arms | 0.141 Nm/Arms |
| Voltage Constant (± 5%) | 8.5 Vrms/Krpm | 8.5 Vrms/Krpm |
| Phase/phase resistance (± 10%@25°C) | 0.14 Ω | 0.12 Ω |
| Phase/phase inductance (± 10%) | 0.53 mH | 0.31 mH |
| Electrical time constant | 3.9 ms | 2.6 ms |
| Thermal Resistance | 1.7 °C/W | 1.3 °C/W |
| Mechanical time constant | 0.66 ms | 1.06 ms |
| Rotor Inertia without brake and without feedback | 0.64 kg·cm² | 1.16 kg·cm² |
| Duet weight | 2.4 Kg | 3.2 Kg |
| Duet weight with brake | 3.1 Kg | 3.9 Kg |
| Axial Load applied on the shaft’s center | 110 N | 110 N |
| Radial Load applied on the shaft’s center | 350 N | 350 N |
| Family Specification | Produkt |
|---|---|
| Time Rating | Coninuous |
| Insulation Class | F |
| Enclosure | Totally enclosed. Self-cooled |
| Protection Class | IP 65 standard on the body |
| Motor Insulation System UL /CSA | cURus , DV155J File nr. : E216686 |
| Ambient Temperature | 0 to 40 °C |
| Ambient Humidity | 5 to 85% (non-condensing) |
| Poles | 8 |
| Certification | CE |
| Recommendation | Rated output with 250 x 250 x 6 mm metallic heat sink flange coupling – Derating must be considered if the oil seal is applied – IP 54 standard shaft bushing – Continuous duty (S1) operation with cooling system appropriately sized. |
| Family Overview | Produkt |
|---|---|
| Flange dimensions | 80 mm |
| Rated Output Power | 390 – 520 Watt |
| Rated Torque | 1,5 – 2,0 Nm |
| Rated Speed | 2500 rpm |
| Fieldbus | CanOpen/Ethercat |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | DUET FLEXI 80 1,5 03 |
|---|---|
| Rated Voltage | 48 Vdc |
| Auxiliary Voltage (+6% -10%) | 24 Vdc |
| Minimum Voltage | 24 Vdc |
| Maximum Voltage | 60 Vdc |
| Stall Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 1.5 Nm |
| Peak Torque | 4.5 Nm |
| Rated Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 1.5 Nm |
| Rated output power @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 390 W |
| Rated output Power @ 10 Arms | 360 W |
| Stall current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 10.7 Arms |
| Peak Current | 32 Arms |
| Rated current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 11 Arms |
| Rated Speed @48Vdc | 2500 rpm |
| Maximum Speed @48Vdc | 3600 rpm |
| Maximum Speed @24Vdc | 1800 rpm |
| Torque Constant (± 5%) | 0.141 Nm/Arms |
| Voltage Constant (± 5%) | 8.5 Vrms/Krpm |
| Phase/phase resistance (± 10%@25°C) | 0.14 Ω |
| Phase/phase inductance (± 10%) | 0.53 mH |
| Electrical time constant | 3.9 ms |
| Thermal Resistance | 1.7 °C/W |
| Mechanical time constant | 0.66 ms |
| Rotor Inertia without brake and without feedback | 0.64 kg·cm² |
| Duet weight | 2.4 Kg |
| Duet weight with brake | 3.1 Kg |
| Axial Load applied on the shaft’s center | 110 N |
| Radial Load applied on the shaft’s center | 350 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | DUET FLEXI 80 2 03 |
|---|---|
| Rated Voltage | 48 Vdc |
| Auxiliary Voltage (+6% -10%) | 24 Vdc |
| Minimum Voltage | 24 Vdc |
| Maximum Voltage | 60 Vdc |
| Stall Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 2 Nm |
| Peak Torque | 5.6 Nm |
| Rated Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 2 Nm |
| Rated output power @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 520 W |
| Rated output Power @ 10 Arms | 360 W |
| Stall current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 14.2 Arms |
| Peak Current | 39.8 Arms |
| Rated current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 14.7 Arms |
| Rated Speed @48Vdc | 2500 rpm |
| Maximum Speed @48Vdc | 3600 rpm |
| Maximum Speed @24Vdc | 1800 rpm |
| Torque Constant (± 5%) | 0.141 Nm/Arms |
| Voltage Constant (± 5%) | 8.5 Vrms/Krpm |
| Phase/phase resistance (± 10%@25°C) | 0.12 Ω |
| Phase/phase inductance (± 10%) | 0.31 mH |
| Electrical time constant | 2.6 ms |
| Thermal Resistance | 1.3 °C/W |
| Mechanical time constant | 1.06 ms |
| Rotor Inertia without brake and without feedback | 1.16 kg·cm² |
| Duet weight | 3.2 Kg |
| Duet weight with brake | 3.9 Kg |
| Axial Load applied on the shaft’s center | 110 N |
| Radial Load applied on the shaft’s center | 350 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
