Produkt
incl. VAT
Flange dimensions: 60 mm
Rated Output Power: 200 – 310 W
Rated Torque: 0,64 – 1,18 Nm
Rated Speed: 2500/3000 rpm
Fieldbus: CanOpen/Ethercat
| Specification | DUET FLEXI 60 0,65 01 | DUET FLEXI 60 1,3 01 |
|---|---|---|
| Rated Voltage | 48 Vdc | 48 Vdc |
| Auxiliary Voltage (+6% -10%) | 24 Vdc | 24 Vdc |
| Minimum Voltage | 24 Vdc | 24 Vdc |
| Maximum Voltage | 60 Vdc | 60 Vdc |
| Stall Torque | 0.65 Nm | – |
| Stall Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | – | 1.3 Nm |
| Peak Torque | 1.95 Nm | 3.75 Nm |
| Rated Torque | 0.64 Nm | – |
| Rated Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 0.64 Nm | 1.18 Nm |
| Rated Output Power | 200 W | – |
| Rated output power @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | – | 310 W |
| Rated output Power @ 10 Arms | – | 240 W |
| Stall Current | 6.9 Arms | – |
| Stall current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | – | 13.9 Arms |
| Peak Current | 20.7 Arms | 39.8 Arms |
| Rated Current | 7 Arms | – |
| Rated current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | – | 12.9 Arms |
| Rated Speed @48Vdc | 3000 rpm | 2500 rpm |
| Maximum Speed @48Vdc | 5000 rpm | 5000 rpm |
| Maximum Speed @24Vdc | 2600 rpm | 2600 rpm |
| Torque Constant (± 5%) | 0.094 Nm/Arms | 0.094 Nm/Arms |
| Voltage Constant (± 5%) | 5.7 Vrms/Krpm | 5.7 Vrms/Krpm |
| Phase/phase resistance (± 10%@25°C) | 0.38 Ω | 0.16 Ω |
| Phase/phase inductance (± 10%) | 0.9 mH | 0.48 mH |
| Electrical time constant | 2.4 ms | 3 ms |
| Thermal Resistance | 1.9 °C/W | 1.4 °C/W |
| Mechanical time constant | 0.83 ms | 0.65 ms |
| Rotor Inertia without brake and without feedback | 0.13 kg·cm² | 0.24 kg·cm² |
| Duet weight | 1.4 Kg | 1.8 Kg |
| Duet weight with brake | 1.8 Kg | 2.2 Kg |
| Axial Load applied on the shaft’s center | 70 N | 70 N |
| Radial Load applied on the shaft’s center | 220 N | 220 N |
| Family Specification | Produkt |
|---|---|
| Insulation Class | F |
| Enclosure | Totally enclosed. Self-cooled |
| Protection Class | IP 65 standard on the body |
| Motor Insulation System UL /CSA | cURus , DV155J File nr. : E216686 |
| Ambient Temperature | 0 to 40 °C |
| Ambient Humidity | 5 to 85% (non-condensing) |
| Poles | 8 |
| Certification | CE |
| Recommendation | Rated output with 250 x 250 x 6 mm metallic heat sink flange coupling – Derating must be considered if the oil seal is applied – IP 54 standard shaft bushing – Continuous duty (S1) operation with cooling system appropriately sized. |
| Family Overview | Produkt |
|---|---|
| Flange dimensions | 60 mm |
| Rated Output Power | 200 – 310 Watt |
| Rated Torque | 0,64 – 1,18 Nm |
| Rated Speed | 2500/3000 rpm |
| Fieldbus | CanOpen/Ethercat |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | DUET FLEXI 60 0,65 01 |
|---|---|
| Rated Voltage | 48 Vdc |
| Auxiliary Voltage (+6% -10%) | 24 Vdc |
| Minimum Voltage | 24 Vdc |
| Maximum Voltage | 60 Vdc |
| Stall Torque | 0.65 Nm |
| Stall Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | – |
| Peak Torque | 1.95 Nm |
| Rated Torque | 0.64 Nm |
| Rated Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 0.64 Nm |
| Rated Output Power | 200 W |
| Rated output power @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | – |
| Rated output Power @ 10 Arms | – |
| Stall Current | 6.9 Arms |
| Stall current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | – |
| Peak Current | 20.7 Arms |
| Rated Current | 7 Arms |
| Rated current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | – |
| Rated Speed @48Vdc | 3000 rpm |
| Maximum Speed @48Vdc | 5000 rpm |
| Maximum Speed @24Vdc | 2600 rpm |
| Torque Constant (± 5%) | 0.094 Nm/Arms |
| Voltage Constant (± 5%) | 5.7 Vrms/Krpm |
| Phase/phase resistance (± 10%@25°C) | 0.38 Ω |
| Phase/phase inductance (± 10%) | 0.9 mH |
| Electrical time constant | 2.4 ms |
| Thermal Resistance | 1.9 °C/W |
| Mechanical time constant | 0.83 ms |
| Rotor Inertia without brake and without feedback | 0.13 kg·cm² |
| Duet weight | 1.4 Kg |
| Duet weight with brake | 1.8 Kg |
| Axial Load applied on the shaft’s center | 70 N |
| Radial Load applied on the shaft’s center | 220 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | DUET FLEXI 60 1,3 01 |
|---|---|
| Rated Voltage | 48 Vdc |
| Auxiliary Voltage (+6% -10%) | 24 Vdc |
| Minimum Voltage | 24 Vdc |
| Maximum Voltage | 60 Vdc |
| Stall Torque | – |
| Stall Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 1.3 Nm |
| Peak Torque | 3.75 Nm |
| Rated Torque | – |
| Rated Torque @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 1.18 Nm |
| Rated Output Power | – |
| Rated output power @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 310 W |
| Rated output Power @ 10 Arms | 240 W |
| Stall Current | – |
| Stall current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 13.9 Arms |
| Peak Current | 39.8 Arms |
| Rated Current | – |
| Rated current @power stage temperature ≤ 50°C (rated current limited to 10 Arms @ power stage temperature > 50°C < 70°C) | 12.9 Arms |
| Rated Speed @48Vdc | 2500 rpm |
| Maximum Speed @48Vdc | 5000 rpm |
| Maximum Speed @24Vdc | 2600 rpm |
| Torque Constant (± 5%) | 0.094 Nm/Arms |
| Voltage Constant (± 5%) | 5.7 Vrms/Krpm |
| Phase/phase resistance (± 10%@25°C) | 0.16 Ω |
| Phase/phase inductance (± 10%) | 0.48 mH |
| Electrical time constant | 3 ms |
| Thermal Resistance | 1.4 °C/W |
| Mechanical time constant | 0.65 ms |
| Rotor Inertia without brake and without feedback | 0.24 kg·cm² |
| Duet weight | 1.8 Kg |
| Duet weight with brake | 2.2 Kg |
| Axial Load applied on the shaft’s center | 70 N |
| Radial Load applied on the shaft’s center | 220 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
