The 1630N5C series is a compact 16mm coreless DC motor equipped with long-life graphite brushes. Offering high efficiency and smooth operation, this motor is ideal for precision drives in medical devices, healthcare equipment, robotics, and industrial automation. Flexible options such as custom shaft lengths, special coils, bearing types, and gear heads are available to meet diverse application requirements.
| Parameter | Unit | 1630N5C09-115-12.0 | 1630N5C07-140-24.0 | 1630N5C11-86-24.0 |
|---|---|---|---|---|
| Voltage | V | 12.0 | 24.0 | 24.0 |
| Terminal resistance | Ω | 5.6 | 14 | 38.3 |
| No-load speed | rpm | 11500 | 14000 | 8600 |
| No-load current | mA | 50 | 30 | 20 |
| Stall torque | mNm | 20.3 | 27 | 15.7 |
| Stall current | mA | 2140 | 1710 | 630 |
| Nominal torque | mNm | 4 | 5 | 4 |
| Nominal speed | rpm | 9240 | 11410 | 6410 |
| Nominal current | mA | 460 | 340 | 180 |
| Max. output power | W | 6.1 | 9.9 | 3.5 |
| Max. efficiency | % | 72 | 75 | 68 |
| Back-EMF constant | mV/rpm | 1 | 1.7 | 2.7 |
| Torque constant | mNm/A | 9.7 | 16.1 | 25.8 |
| Speed/torque gradient | rpm/mNm | 600 | 500 | 500 |
| Rotor inertia | gcm² | 0.95 | 0.95 | 0.95 |
| Weight | g | 25 | 25 | 25 |
| Thermal resistance housing-ambient | K/W | 26.8 | 26.8 | 26.8 |
| Thermal resistance winding-housing | K/W | 30.6 | 30.6 | 30.6 |
| Thermal time constant motor | s | 242 | 242 | 242 |
| Thermal time constant winding | s | 232 | 232 | 232 |
| Operating temperature range | °C | -20~+85 | -20~+85 | -20~+85 |
| Thermal class of winding | °C | 130 | 130 | 130 |
| Axial play | mm | 0.02~0.15 | 0.02~0.15 | 0.02~0.15 |
| Radial play | mm | 0.014 | 0.014 | 0.014 |
| Axial load dynamic | N | 0.8 | 0.8 | 0.8 |
| Axial load static | N | 30 | 30 | 30 |
| Radial load at 3 mm from mounting face | N | 1.4 | 1.4 | 1.4 |
| No. of pole pairs | 1 | 1 | 1 | |
| Bearings | 2 sleeve bearings | 2 sleeve bearings | 2 sleeve bearings | |
| Commutator | graphite 5 segments | graphite 5 segments | graphite 5 segments | |
| Protection class | IP | 30 | 30 | 30 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Parameter | Unit | 1630N5C09-115-12.0 |
|---|---|---|
| Voltage | V | 12.0 |
| Terminal resistance | Ω | 5.6 |
| No-load speed | rpm | 11500 |
| No-load current | mA | 50 |
| Stall torque | mNm | 20.3 |
| Stall current | mA | 2140 |
| Nominal torque | mNm | 4 |
| Nominal speed | rpm | 9240 |
| Nominal current | mA | 460 |
| Max. output power | W | 6.1 |
| Max. efficiency | % | 72 |
| Back-EMF constant | mV/rpm | 1 |
| Torque constant | mNm/A | 9.7 |
| Speed/torque gradient | rpm/mNm | 600 |
| Rotor inertia | gcm² | 0.95 |
| Weight | g | 25 |
| Thermal resistance housing-ambient | K/W | 26.8 |
| Thermal resistance winding-housing | K/W | 30.6 |
| Thermal time constant motor | s | 242 |
| Thermal time constant winding | s | 232 |
| Operating temperature range | °C | -20~+85 |
| Thermal class of winding | °C | 130 |
| Axial play | mm | 0.02~0.15 |
| Radial play | mm | 0.014 |
| Axial load dynamic | N | 0.8 |
| Axial load static | N | 30 |
| Radial load at 3 mm from mounting face | N | 1.4 |
| No. of pole pairs | 1 | |
| Bearings | 2 sleeve bearings | |
| Commutator | graphite 5 segments | |
| Protection class | IP | 30 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Parameter | Unit | 1630N5C07-140-24.0 |
|---|---|---|
| Voltage | V | 24.0 |
| Terminal resistance | Ω | 14 |
| No-load speed | rpm | 14000 |
| No-load current | mA | 30 |
| Stall torque | mNm | 27 |
| Stall current | mA | 1710 |
| Nominal torque | mNm | 5 |
| Nominal speed | rpm | 11410 |
| Nominal current | mA | 340 |
| Max. output power | W | 9.9 |
| Max. efficiency | % | 75 |
| Back-EMF constant | mV/rpm | 1.7 |
| Torque constant | mNm/A | 16.1 |
| Speed/torque gradient | rpm/mNm | 500 |
| Rotor inertia | gcm² | 0.95 |
| Weight | g | 25 |
| Thermal resistance housing-ambient | K/W | 26.8 |
| Thermal resistance winding-housing | K/W | 30.6 |
| Thermal time constant motor | s | 242 |
| Thermal time constant winding | s | 232 |
| Operating temperature range | °C | -20~+85 |
| Thermal class of winding | °C | 130 |
| Axial play | mm | 0.02~0.15 |
| Radial play | mm | 0.014 |
| Axial load dynamic | N | 0.8 |
| Axial load static | N | 30 |
| Radial load at 3 mm from mounting face | N | 1.4 |
| No. of pole pairs | 1 | |
| Bearings | 2 sleeve bearings | |
| Commutator | graphite 5 segments | |
| Protection class | IP | 30 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Parameter | Unit | 1630N5C11-86-24.0 |
|---|---|---|
| Voltage | V | 24.0 |
| Terminal resistance | Ω | 38.3 |
| No-load speed | rpm | 8600 |
| No-load current | mA | 20 |
| Stall torque | mNm | 15.7 |
| Stall current | mA | 630 |
| Nominal torque | mNm | 4 |
| Nominal speed | rpm | 6410 |
| Nominal current | mA | 180 |
| Max. output power | W | 3.5 |
| Max. efficiency | % | 68 |
| Back-EMF constant | mV/rpm | 2.7 |
| Torque constant | mNm/A | 25.8 |
| Speed/torque gradient | rpm/mNm | 500 |
| Rotor inertia | gcm² | 0.95 |
| Weight | g | 25 |
| Thermal resistance housing-ambient | K/W | 26.8 |
| Thermal resistance winding-housing | K/W | 30.6 |
| Thermal time constant motor | s | 242 |
| Thermal time constant winding | s | 232 |
| Operating temperature range | °C | -20~+85 |
| Thermal class of winding | °C | 130 |
| Axial play | mm | 0.02~0.15 |
| Radial play | mm | 0.014 |
| Axial load dynamic | N | 0.8 |
| Axial load static | N | 30 |
| Radial load at 3 mm from mounting face | N | 1.4 |
| No. of pole pairs | 1 | |
| Bearings | 2 sleeve bearings | |
| Commutator | graphite 5 segments | |
| Protection class | IP | 30 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
