| Characteristics | L1215N5M43-230-6.0 | L1215N5M48-330-8.0 | L1215N5M34-280-6.0 |
|---|---|---|---|
| Voltage | 6.0 V | 8.0 V | 6.0 V |
| Terminal resistance | 3.4 Ω | 3.3 Ω | 2.3 Ω |
| No-load speed | 23000 rpm | 33000 rpm | 28000 rpm |
| No-load current | 50 mA | 80 mA | 70 mA |
| Stall torque | 4.1 mNm | 5.2 mNm | 5.1 mNm |
| Stall current | 1760 mA | 2420 mA | 2610 mA |
| Load torque | 1 mNm | 1 mNm | 0.5 mNm |
| Load speed | 20220 rpm | 29850 rpm | 25230 rpm |
| Load current | 260 mA | 300 mA | 320 mA |
| Max. output power | 2 W | 5 W | 3.7 W |
| Max. efficiency | 69.2 % | 67 % | 70 % |
| Back-EMF constant | 0.3 mV/rpm | 0.2 mV/rpm | 0.2 mV/rpm |
| Torque constant | 2.4 mNm/A | 2.2 mNm/A | 2.0 mNm/A |
| Speed/torque gradient | 5560 rpm/mNm | 6300 rpm/mNm | 5540 rpm/mNm |
| Rotor inertia | 0.1 g·cm² | 0.1 g·cm² | 0.1 g·cm² |
| Weight | 7 g | 7 g | 6.5 g |
| Operating temperature range | -20~+85 | -20~+85 | -20~+85 |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | L1215N5M43-230-6.0 |
|---|---|
| Voltage | 6.0 V |
| Terminal resistance | 3.4 Ω |
| No-load speed | 23000 rpm |
| No-load current | 50 mA |
| Stall torque | 4.1 mNm |
| Stall current | 1760 mA |
| Load torque | 1 mNm |
| Load speed | 20220 rpm |
| Load current | 260 mA |
| Max. output power | 2 W |
| Max. efficiency | 69.2 % |
| Back-EMF constant | 0.3 mV/rpm |
| Torque constant | 2.4 mNm/A |
| Speed/torque gradient | 5560 rpm/mNm |
| Rotor inertia | 0.1 g·cm² |
| Weight | 7 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | L1215N5M48-330-8.0 |
|---|---|
| Voltage | 8.0 V |
| Terminal resistance | 3.3 Ω |
| No-load speed | 33000 rpm |
| No-load current | 80 mA |
| Stall torque | 5.2 mNm |
| Stall current | 2420 mA |
| Load torque | 1 mNm |
| Load speed | 29850 rpm |
| Load current | 300 mA |
| Max. output power | 5 W |
| Max. efficiency | 67 % |
| Back-EMF constant | 0.2 mV/rpm |
| Torque constant | 2.2 mNm/A |
| Speed/torque gradient | 6300 rpm/mNm |
| Rotor inertia | 0.1 g·cm² |
| Weight | 7 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | L1215N5M34-280-6.0 |
|---|---|
| Voltage | 6.0 V |
| Terminal resistance | 2.3 Ω |
| No-load speed | 28000 rpm |
| No-load current | 70 mA |
| Stall torque | 5.1 mNm |
| Stall current | 2610 mA |
| Load torque | 0.5 mNm |
| Load speed | 25230 rpm |
| Load current | 320 mA |
| Max. output power | 3.7 W |
| Max. efficiency | 70 % |
| Back-EMF constant | 0.2 mV/rpm |
| Torque constant | 2.0 mNm/A |
| Speed/torque gradient | 5540 rpm/mNm |
| Rotor inertia | 0.1 g·cm² |
| Weight | 6.5 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
