| Motor Characteristics | 10**—10*P—1020N5M52-115-3.0 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 3.8 Ω |
| No-load speed | 11500 rpm |
| No-load current | 16 mA |
| Stall torque | 1.89 mNm |
| Stall current | 790 mA |
| Nominal torque | 0.50 mNm |
| Nominal speed | 8460 rpm |
| Nominal current | 220 mA |
| Max. output power | 0.57 W |
| Max. efficiency | 74 % |
| Back-EMF constant | 0.26 mV/rpm |
| Torque constant | 2.44 mNm/A |
| Speed/torque gradient | 6088 rpm/mNm |
| Rotor inertia | 0.07 g·cm² |
| Weight | 6.1 g |
| Gearbox characteristics | Produkt | ||
|---|---|---|---|
| Gearbox stages | 1 | ||
| Reduction ratio | 4 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
||
| Gearbox stages | 2 | ||
| Reduction ratio | 16 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
||
| Gearbox stages | 3 | ||
| Reduction ratio | 64 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
||
| Gearbox stages | 4 | ||
| Reduction ratio | 256 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
||
| Gearbox stages | 5 | ||
| Reduction ratio | 1024 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
||
| Gearbox stages | 6 | ||
| Reduction ratio | 4096 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
Applications
medical equipment
scientific instruments
industrial equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | 10**—10*P—1020N5M52-115-3.0 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 3.8 Ω |
| No-load speed | 11500 rpm |
| No-load current | 16 mA |
| Stall torque | 1.89 mNm |
| Stall current | 790 mA |
| Nominal torque | 0.50 mNm |
| Nominal speed | 8460 rpm |
| Nominal current | 220 mA |
| Max. output power | 0.57 W |
| Max. efficiency | 74 % |
| Back-EMF constant | 0.26 mV/rpm |
| Torque constant | 2.44 mNm/A |
| Speed/torque gradient | 6088 rpm/mNm |
| Rotor inertia | 0.07 g·cm² |
| Weight | 6.1 g |
Applications
medical equipment
scientific instruments
industrial equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
